悬臂柔性转子动力特性及高速动平衡试验

邓旺群; 高德平

悬臂柔性转子动力特性及高速动平衡试验

邓旺群^1,2,
高德平¹

1.
南京航空航天大学能源与动力学院, 江苏南京 210016
2.
中国航空动力机械研究所, 湖南株洲 412002

计量
- 文章访问数: 1570
- HTML浏览量: 3
- PDF量: 410
- 被引次数: 0
出版历程
- 收稿日期: 2005-04-22
- 修回日期: 2006-01-18
- 刊出日期: 2006-06-28

Experimental Investigation on Dynamic Characteristics and High Speed Dynamic Balance of a Cantilever Flexible Rotor

DENG Wang-qun^1,2,
GAO De-ping¹

1.
College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China
2.
China Aviation Powerplant Research Institute, Zhuzhou 412002, China

摘要

摘要: 试验研究了装不同弹性支承和金属橡胶阻尼器(组合支承)的火箭发动机氧涡轮泵转子的动力特性,并对装优选出的组合支承的转子进行了高速动平衡及重复性考核试验。结果表明:悬臂柔性转子的动力特性可以通过支承的优化组合而得到改善,单面平衡技术大幅度减小了转子的动挠度和弹支的动应力,分解和重新装配所带来的装配不平衡不会实质性的影响转子原有的平衡状态。
- 航空、航天推进系统 /
- 动力特性 /
- 高速动平衡 /
- 装配不平衡
Abstract: More than 20 dynamic characteristic experiments of rocket engine oxygen turbopump rotor with different combination of elastic support and metal-rubber damper(combined bearing) were conducted.High speed dynamic balance and repeatability check experiments of the rotor were also conducted with an optimum combined bearing.The results show that the dynamic characteristics of cantilever flexible rotor can be improved by optimum combination of elastic support and metal-rubber damper.The dynamic deflection of the rotor and the dynamic stress of the elastic support can significantly be reduced by single plane high speed dynamic balance technique,and additional unbalance caused by disassembly and assembly will not materially destroy the original balance so long as the accuracy of balancing and the quality of assembly are ensured.
- aerospace propulsion system /
- rocket engine /
- oxygen turbopump rotor /
- dynamic characteristics

HTML

参考文献(5)

[1]	付才高,郑大平,欧园霞,周松江,赵行明编.转子动力学及整机振动(航空发动机设计手册第19册)[M].北京:航空工业出版社,2000.
[2]	邓旺群,高德平.涡轴发动机动力涡轮转子高速动平衡技术研究[J].航空动力学报,2003,18(5):669～675.Deng Wangqun,Gao Deping.High Speed Dynamic Balance Technique of a Power Turbine Rotor of a Turbine Shaft Engine[J].Journal of Aerospace Power,2003,18 (5):669～675.
[3]	邓旺群,高德平.涡轴发动机动力涡轮转子动力特性研究[J].航空动力学报,2003,18(6):717～722.Deng Wangqun,Gao Deping.Dynamic Characteristics Study of a Power Turbine Rotor of a Turbine Shaft Engine[J].Journal of Aerospace Power,2003,18(6):717～722.
[4]	郭宝亭,朱梓根.金属橡胶阻尼器在转子系统中的应用[J].航空动力学报,2003,18(5):662～668.Guo Baoting,Zhu Zigen.Application of Metal-Rubber Damper to the Rotor System[J].Journalof Aerospace Power,2003,18(5):662-668.
[5]	许建东,郭宝亭,朱梓根,李其汉.金属橡胶材料的振动特性[J].航空动力学报,2004,19(5):619～622.Xu Jiandong,Guo Baoting,Zhu Zigen,Li Qihan.The Vibration Performance of Metal-Rubber Material[J].Journal of Aerospace Power,2004,19(5):619～622.
