某风扇/增压级非设计点性能计算及进气畸变影响分析

赵勇; 胡骏

某风扇/增压级非设计点性能计算及进气畸变影响分析

赵勇,
胡骏

南京航空航天大学能源与动力学院, 南京 210016

基金项目: 国防科研计划资助项目

计量
- 文章访问数: 1848
- HTML浏览量: 123
- PDF量: 444
- 被引次数: 0
出版历程
- 收稿日期: 2006-06-12
- 修回日期: 2006-11-21
- 刊出日期: 2007-07-28

Analysis of the influence of inlet flow distortion on the off-design performance of fan/booster

ZHAO Yong,
HU Jun

College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 在原流线曲率法程序的基础上, 增加了适用于高速风扇/压气机的双激波损失模型.真实地反映了高速风扇/压气机的实际工作状况, 提高了预测高速风扇/压气机非设计点性能的准确性, 完善了分析进气畸变对风扇/压气机性能及稳定性影响的准三维计算模型.针对一台外涵转子叶尖马赫数大于1.4的大涵道比风扇/增压级, 计算分析了其非设计点性能以及进气畸变的影响.计算结果与试验结果吻合较好, 精度可靠, 可应用于工程实际.
- 航空、航天推进系统 /
- 风扇/增压级 /
- 流线曲率法 /
- 进气畸变 /
- 激盘
Abstract: A dual-shock loss model suitable for high-speed fan/compressor is incorporated into the streamline curvature method to estimate the actual operating condition of high-speed fan/compressor.Moreover,it helps to improve the accuracy of predicting the fan/compressor off-design performance,and further develop the quasi-3D model used to analyze the influence of the inlet flow distortion on the performance and stability of fan/compressor.For a high bypass ratio fan/booster with the Mach number lager than 1.4,the off-design performance and influence of inlet flow distortion is calculated and analyzed.The accurate calculated results,identical to the experimental results,are suitable for engineering applications.
- aerospace propulsion system /
- fan/booster /
- streamline curvature methods /
- inlet flow distortion /
- actuator disk

HTML

参考文献(13)

[1]	Robbins W H,Dugan J F.Prediction of off-design performance of multistage compressors[R].NASA SP-36,Chapter X,1965:297-310.
[2]	周燕佩,徐力平.计算流体动力学在航空叶轮机械中的应用一现状和展望[C]//21世纪航空动力发展研讨会.北京:中国航空动力专业分会,2000:100-104.
[3]	Johnsen I A,Bullock R O,Aerodynamic design of axialflow compressor[R].NASA SP-36.1965.
[4]	胡骏.均匀与非均匀进气条件下多级轴流压气机性能计算-均匀进气及径向畸变的影响[J].航空动力学报,2000,15(3):225-228.HU Jun.Calculation of off design performance of multistage compressors with uniform and radial distorted Inlet flow[J].Journal of Aerospace Power,2000,15(3):225-228.
[5]	燃气涡轮发动机进口流场畸变评审方法[R].北京:航空航天工业部301研究所,1989.
[6]	Gas turbine engine inlet flow distortion guideline[R].Society of Automotive Engineers,Inc,ARP-1420,March 1978.
[7]	Inlet total pressure distortion considerations for gas turbine engines[R].Society of Automotive Engineers,Ine.,AIR-1419,MAY 1983.
[8]	Miller G R.Shock losses in transonic compressor blade rows[J].ASME Journal of Engineering for Power,1961,83:235-242.
[9]	Bloch G S,Copenhaver W W,O'Brien W F.A shock loss model for supersonic compressor cascade[J].ASME Journal of Turbomachinery,1999,121(1):28-35.
[10]	Bloch G S,Copenhaver W W,O'Brien W F.Development of an off-design loss model for transonic compressor design[C]//Loss Mechanisms and Unsteady Flows in Turbomachines,AGARD-CP-571,Neuilly Sur Seine,France,NATO Research and Technology Organization,1996:16-1-16-14.
[11]	Boyer K M,O'Brien W F.An improved streamline curvature approach for off-design analysis of transonic axial compression systems[J].ASME Journal of Turbomachinery,2003,125(3):475-481.
[12]	赵勇,胡骏,郑大勇.用双激波模型计算风扇/压气机非设计点的性能[J].南京航空航天大学学报,2006,38(5):545-550.ZHAO Yong,HU Jun,ZHENG Dayong.Dual-shock loss model for off-design performance calculation of fan/compressor[J].Journal of Nanjing University of Aeronautics & Astronautics,2006,38(5):545-550.
[13]	胡骏.均匀与非均匀进气条件下多级轴流压气机性能计算-周向畸变的影响[J].航空动力学报,2000,15(3):229-232.HU Jun.Calculation of off-design performance of multistage compressor with circumferential distorted Inlet flow[J].Journal of Aerospace Power,2000,15(3):229-232.
