带旋流杯的模型回流燃烧室主燃孔射流研究

孟江涛; 黄勇; 郭志辉; 许旭

带旋流杯的模型回流燃烧室主燃孔射流研究

北京航空航天大学能源与动力工程学院, 北京 100083

计量
- 文章访问数: 1994
- HTML浏览量: 150
- PDF量: 446
- 被引次数: 0
出版历程
- 收稿日期: 2006-06-21
- 修回日期: 2007-02-12
- 刊出日期: 2007-07-28

Research on primary jet of a reverse flow combustor model with swirl cup

School of Jet Propulsion, Beijing University of Aeronautics and Astronautics, 100083, China

摘要

摘要: 实验研究了带轴径向旋流杯、主燃孔和冷却气流的模型回流燃烧室在工作压力为300 kPa, 燃烧室压力损失为2.5%时主燃孔射流的特点以及其对燃烧室流场的影响.结果表明, 回流式燃烧室内外壁主燃孔射流进气方向与顺流式燃烧室不同, 即内壁主燃孔射流向流动方向下游倾斜, 外壁主燃孔射流向流动方向上游倾斜;主燃孔射流穿透深度很大, 几乎能穿透到对面火焰筒壁;中心回流区长度明显缩短, 其长度L与旋流杯出口直径D的比值(L/D)约为0.5, 而常规的顺流式燃烧室的L/D约为1.3.
- 航空、航天推进系统 /
- 回流燃烧室 /
- 旋流杯 /
- 主燃孔 /
- 速度场 /
- 回流区
Abstract: The characteristics of primary jets and its effects on the velocity field of reverse flow combustor model,which primarily comprising an axial-radial swirl cup and a primary hole with cooling air,was studied experimentally in the case of operating pressure of 300Kpa and pressure lose of combustor of 2.5%.The results show that,the air intake direction of primary jets into the reverse flow combustor differs from that of straight-flow combustors,namely,the inner jets inclined to downstream direction,and the outer jets inclined to upstream direction.The penetration of the primary jets is very deep to reach almost the opposite liner wall.And,the length of the recirculation zone is shortened remarkably,with L/D(length to diameter of swirl cup) about 0.5D,and L/D of typical straight-flow combustor about 1.3.
- aerospace propulsion system /
- revers flow combustors /
- swirl cup /
- primary holes /
- velocity profile /
- recirculation zone

HTML

参考文献(7)

[1]	Mellor A M.Design of modern turbine combustors[M].Academic Press,1990.
[2]	Mongia H C,Al-Roub M,Danis A.Swirl cup modeling part 1[R].AIAA 2001-3576.
[3]	FENG Shouyi,HUANG Yong,GUO Zhihui.Experiments on the spray in a model cumbustor with swirl cup and primary hole[C]//The 9th Annual conference on Liquid Atomization and Spray Systems-Asian.August 22-24,2004,Shanghai:P.R.China.
[4]	黄勇、郭志辉.某燃烧室头部旋流油雾场特性的实验研究[C]//中国航空学会第五届动力年会.北京:中国航空学会动力专业分会,5:103-110,2003.
[5]	Manampathy G G,Hukam C M,Ghanshyam S.Swirl cup modeling part Ⅵ:dilution jet modeling[R].AIAA 2003-1203.
[6]	朗洪俭,郭志辉,黄勇.主燃孔对旋流杯下游流场的影响[J].推进技术,2006,27(2):110-113.LANG Hongjian,GUO Zhihui,HUANG Yong,Effect of primary holes on the velocity profiles downstream of a swirl cup[J].Journal of Propulsion Technology,2006,27(2):110-113.
[7]	LANG Hongjian,GUO Zhihui,HUANG Yong.The flowfields in a model combustor with primary holes after different swirl cup[R].ASME Turbo Expo 2006,ASMEGT2006-90489.
