基于RBF网络的质量矩导弹姿态控制
Moving-mass attitude control system based on RBF networks
-
摘要: 研究了三轴稳定质量矩导弹姿态控制问题.建立了内部带有3个可移动滑块的数学模型.利用RBF(radial basis function)网络的快速自学习、自适应特性, 作为被控对象的模型, 不断调整PID控制器的参数, 协调控制滑块位置, 从而改变导弹的飞行姿态.最后讨论了滑块运动特性对系统性能的影响并对系统稳定性进行了分析.仿真结果表明该控制律在保证系统稳定的情况下有效地实现导弹的姿态调整, 并且提高了系统的动态响应品质.Abstract: The ability of moving-mass attitude control system to control a vehicle with three-axial stabilization in intra-atmospheric space is investigated.And general nonlinear motion equations with three internal moving masses are provided.Utilizing on the fast self-learning and adaptive capacities of RBF(radial basis function) networks,use them as the identification of the object under control to tune the PID(proportional integral differential) controller's parameters.The masses are positioned independently to generate modest attitude corrections for the vehicle.Finally,the influence of moving masses' motion on the system performance is discussed and the system stability is analyzed.Simulation results show that the system stabilization can be ensured while effective attitude adjustment for the vehicle is effected and at the same time the system's dynamic performances are improved.
-
[1] Menon P K,Sweriduk G D,Ohlmeyer E J.Inte-grated guidance and control of moving mass actuated kinetic warheads[J].Journal of Guidance,Control and Dynamics,2004,27(1):118-126. [2] Robinet C R D,Rain water B.Moving mass trim control for aerospace vehicles[J].Journal of Guidance,Control and Dynamics,1996,19(5):1064-1079. [3] Lyshevski S E.Space transformation method in control of agile Interceptors and missile with advanced microelectro-mechanical actuators[C] // Proceeding of the 42nd IEEE Conference on Decision and Control.Maul,Hawaii:USA.2003:543-547. [4] Woolsey C A,Leonard N E.Moving mass control for underwater vehicles[C]//Proceedings of the American Control Conference.Anchorage:AK May 8-10,2002:2824-2829. [5] Petsopoulos T,Regan FJ,Barlow J.Moving-mass roll control system for fixed-trim re-entry vehi-cle[J].Journal of Spacecraft and Rockets,1996,33(1):54-60. [6] 徐丽娜.神经网络控制[M].北京:电子工业出版社,2003:203-212.
