二元引射喷管几何特征参数对推力及红外特性的影响

刘福城; 吉洪湖; 林兰之; 黄伟; 刘常春; 斯仁

二元引射喷管几何特征参数对推力及红外特性的影响

南京航空航天大学能源与动力学院,南京 210016

计量
- 文章访问数: 2140
- HTML浏览量: 202
- PDF量: 27
- 被引次数: 0
出版历程
- 收稿日期: 2010-05-13
- 修回日期: 2010-09-27
- 刊出日期: 2011-06-28

Impact of geometry parameters on the thrust and infrared radiation characteristics of two-dimensional ejector nozzle

College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics,Nanjing 210016,China

摘要

摘要: 采用数值模拟的方法研究了二元引射喷管间距比变化和面积比变化对推力特性和3~5μm波段红外辐射特性的影响.排气系统的流场采用了商用软件计算,红外辐射特征采用了自主开发的软件(NUAA-IR)进行计算.结果表明:间距比变化和面积比变化对二元引射喷管的推力系数和引射流量比有不同程度的影响.在小方向角范围内,间距比和面积比的变化对宽边探测平面上的积分辐射强度影响较大,最大降幅为30%左右,而对窄边探测平面上的积分辐射强度影响较小;二元引射喷管相对于二元喷管的红外辐射特性最大降幅为50%左右.
- 二元引射喷管 /
- 间距比 /
- 面积比 /
- 推力特性 /
- 红外辐射
Abstract: The thrust and infrared radiation(IR) characteristics in the waveband of 3~5 μm of two-dimensional(2-D) ejector nozzle were studied numerically.The flow field of the exhaust jet was calculated with commercial software.The infrared radiation characteristics were calculated with an IR analysis software (NUAA-IR) developed by our research group.The results show that spacing ratio and area ratio have different impacts on the thrust ratio and mass-flow ratio of the 2-D ejector nozzle.Spacing ratio and area ratio have greater impact on wide detected plane within a small azimuth angles.In relation to a 2-D nozzle,the integral IR intensity of a 2-D ejector nozzle can be reduced about 50%.
- two-dimensional(2-D) ejector nozzle /
- spacing ratio /
- area ratio /

HTML

参考文献(12)

[1]	张勃,吉洪湖.大宽高比矩形喷管的射流与外流的掺混特性的数值研究[J].航空动力学报,2005,20(1):104-110. ZHANG Bo,JI Honghu.Numerical study of internal and external flow mixing for rectangular nozzles with large aspect ratio[J].Journal of Aerospace Power,2005,20(1):104-110.(in Chinese)
[2]	林兰之.采用二元引射喷管的无人机红外隐身技术数值模拟研究 .南京:南京航空航天大学,2009. LIN Lanzhi.Numerical simulation of infrared stealth technology of the unmanned aerial vehicle with a mounted two dimensional ejector nozzle .Nanjing:Nanjing University of Aeronautics and Astronautics,2009.(in Chinese)
[3]	李黎.排气引射系统主喷管选型试验研究[J].航空动力学报,1998,13(1):85-88. LI Li.An experimental study on primary nozzle types of exhaust ejector systems[J].Journal of Aerospace Power,1998,13(1):85-88.(in Chinese)
[4]	王广振,吴寿生,王之珊,等.混合管面积和位置对排气引射器性能的影响[J].推进技术,2000,21(4):20-23. WANG Guangzhen,WU Shousheng,WANG Zhishan,et al.Effect of mixing tube area and position on performances for lobed ejector[J].Journal of Propulsion Technology,2000,21(4):20-23.(in Chinese)
[5]	额日其太,王志杰,吴寿生,等.高速热喷流条件下二元收扩喷管扩张段壁面冷却的初步试验研究[J].航空动力学报,2002,17(1):40-44. Eriqitai,WANG Zhijie,WU Shousheng,et al.Preliminary experimental investigation on the divergent wall cooling of two dimensional 2-D nozzles at high speed and hot jet conditions[J].Journal of Aerospace Power,2002,17(1):40-44.(in Chinese)
[6]	Greathouse W K,Hollister D P.Preliminary air-flow and thrust calibrations of several conical cooling-air ejectors with a primary to secondary temperature ratio of 1.0Ⅰ:diameter ratios of 1.21 and 1.10 .NACA RM E52E21,1952.
[7]	Choi Y H,Soh W Y.Computational analysis of the flowfield of a two-dimensional ejector nozzle .AIAA-90-190,1990.
[8]	王强,额日其太,王宏波,等.利用ENSAAP程序计算喷管超音速壁面排气引射冷却系统性能与分析[J].航空动力学报,2001,16(4):381-385. WANG Qiang,Eriqitai,WANG Hongbo,et al.Performance investigation of multi-slot ejector nozzles for high speed exhaust system[J].Journal of Aerospace Power,2001,16(4):381-385.(in Chinese)
[9]	Li H J,Shen S Q.Comparison of turbulence models applied to the calculation of flow in ejector //Proceedings of the Fourth International Conference on Fluid Mechanics.Dalian:Tsinghua University Press and Springer-Verlag,2004:20-23.
[10]	罗明东.无人机排气系统红外隐身技术研究 .南京:南京航空航天大学,2006. LUO Mingdong.Investigation of infrared stealth technology of the exhaust system for unmanned aerial vehicle .Nanjing:Nanjing University of Aeronautics and Astronautics,2006.(in Chinese)
[11]	《航空发动机设计手册》总编委会.航空发动机设计手册第七册——进排气装置[M].北京:航空工业出版社,2002.
[12]	徐南荣.热空腔-喷气流的组合辐射[J].航空动力学报,1995,10(3):295-298. XU Nanrong.Thermal cavity-plume combination radiation[J].Journal of Aerospace Power,1995,10(3):295-298.(in Chinese)
