薄板孔边挤压强化对低循环疲劳寿命影响的试验

杨兴宇; 王逾涯; 董立伟; 孟祥明; 脱伟

薄板孔边挤压强化对低循环疲劳寿命影响的试验

北京航空工程技术研究中心,北京 100076

计量
- 文章访问数: 2125
- HTML浏览量: 264
- PDF量: 22
- 被引次数: 0
出版历程
- 收稿日期: 2010-05-19
- 修回日期: 2010-09-27
- 刊出日期: 2011-06-28

Low cycle fatigue life experiment of sheet metal with coldworking hole

Beijing Aeronautical Engineering Technical Research Center,Beijing 100076,China

摘要

摘要: 为提高某压气机封严篦齿盘均压孔的疲劳强度,根据均压孔的具体结构形式,设计了三种冷挤压强化方法:单侧多次挤压法、柱形头挤压法和T形头挤压法.用两种材料(不锈钢1Cr11Ni2W2MoV和镍基高温合金ЗП742)设计加工了低循环疲劳薄板有孔模拟件,用两种工艺强化薄板有孔模拟件,同时进行了室温和高温温度的低循环疲劳对比考核试验.试验结果表明,对于薄板倒圆孔,T形头挤压工艺强化效果较好,可以有效提高薄板有孔模拟件的低循环疲劳寿命;在同样的强化工艺条件下,低循环疲劳载荷大小影响强化效果,载荷越小效果越明显.
- 薄板有孔模拟件 /
- 疲劳强度 /
- 挤压强化 /
- 低循环疲劳 /
- 对比试验
Abstract: In order to enhance the fatigue strength of the pressure equalizing hole on labyrinth seal disc for a compressor,three kinds of coldworking techniques with different processes were designed,namely,one-sided multiple extrusion process,cylindrical extrusion process and T shape extrusion process.Simulations on sheet metal with hole specimen for low cycle fatigue experimentation were designed using two kinds of materials(stainless steel 1Cr11Ni2W2MoV and high temperature nickel-alloy ЗП742).Sheet metal with hole specimen was strengthened using two kinds of coldworking techniques,namely,single-side and repetitious extrusion method and T head extrusion method.And contrastive low cycle fatigue experimentation was done under two kinds of experiment temperatures,i.e.normal temperature and high temperature.The experimentation and analysis was made for different fatigue loads on how to influence the strength effect.The experiment results show that the effect of T head coldworking techniques is better for sheet metal filleted hole to improve low-cycle fatigue intension of the sheet metal with hole simulation specimen effectively.Under the same strength technique conditions,the size of low cycle fatigue load will influence the strength effect,and the smaller load means more obvious effect.
- sheet metal specimen with hole /
- fatigue strength /
- coldworking /

HTML

参考文献(13)

[1]	中国航空科学技术研究院.飞机结构抗疲劳断裂强化设计手册[M].北京:航空工业出版社,1993.
[2]	中国航空科学技术研究院.飞机结构抗疲劳断裂强化工艺手册[M].北京:航空工业出版社,1993.
[3]	Reid L.Split sleeve cold expansion as a rework process for previously cold expanded holes .Stockholm,Sweden:ICAF’ 93 International Committee on Aeronautical Faigue, 1993.
[4]	Link R E,Sanford R J.Residual strains surrounding split-sleeve cold expanded holes in 7075-T651 aluminum[J].J.Aircraft,1990,27(7):599-604.
[5]	Gaerke J,Zhang X,Wang Z.Life enhancement of fatigue-aged fastener holes using the cold expansion process[J].Journal of Aerospace Engineering,2000,214(5):281-293.
[6]	王智,李京珊.影响冷挤压强化效果的因素[J].机械强度2002,24(2):302-304. WANG Zhi,LI Jingshan.Factors of influencing the beneficial effect of cold expansion[J].Journal of Mechanical Strength,2002,24(2):302-304.(in Chinese)
[7]	杨兴宇,孟祥明,董立伟.薄板孔边挤压强化对高周疲劳寿命影响的试验[J].航空动力学报,2011,26(2):361-369. YANG Xingyu,MENG Xiangming,DONG Liwei.High cycle fatigue life experiment of sheet metal with coldworking hole[J].Journal of Aerospace Power,2011,26(2):361-369.(in Chinese)
[8]	蒋金龙,赵名泮.冷挤压孔板残余应力场分析[J].航空学报,1991,12(10):511-513. JIANG Jinlong,ZHAO Mingpan.Analysis of residual stress field at coldworking fastener hole[J].Acta Aeronautica et Astronautica Sinica,1991,12(10):511-513.(in Chinese)
[9]	何世平,张曦,伍小平.铰孔和疲劳对冷挤压孔周残余应力的影响[J].实验力学,1996,11(4):463-467. HE Shiping,ZHANG Xi,WU Xiaoping.The influence of reaming and fatigue on the redual stress around cold-expanded holes[J].Journal of Experimental Mechanics,1996,11(4):463-467.(in Chinese)
[10]	Carey R P,Hoskin B C.A finite element procedure for interference-fit and cold-working probloms with limited yielding .Melboucme,Australia:Dept.Defence,Aeronautical Research Laboratories,Structures Report 425,1986.
[11]	米谷茂.残余应力的产生和对策[M].朱荆璞,邵会孟,译.北京:机械工业出版社,1983.
[12]	Bernard M,Bui-Quoc T,Burlat M.Effect of re-coldworking on fatigue life enhancement of a fastener hole[J].Fatigue & Fracture of Engineering Materials & Structures,1995,18(7/8):765-775.
[13]	Cathey W H,Grandt A F,Jr.Fracture mechanics consideration of residual stresses introduced by coldworking fastener holes[J].Journal of Engineering Materials and Technology,1980,102(1):85-91.
