双向顺序耦合法求解动力响应的试验验证

张大义; 马艳红; 洪杰; 陈璐璐

双向顺序耦合法求解动力响应的试验验证

北京航空航天大学能源与动力工程学院,北京 100191

计量
- 文章访问数: 1723
- HTML浏览量: 231
- PDF量: 23
- 被引次数: 0
出版历程
- 收稿日期: 2010-05-19
- 修回日期: 2010-07-18
- 刊出日期: 2011-06-28

Experimental verification on bidirectional sequential method to solve dynamical response caused by aerodynamic loads

School of Jet Propulsion, Beijing University of Aeronautics and Astronautics,Beijing 100191,China

摘要

摘要: 为验证双向顺序耦合法求解的可信性,设计并建立一套气流激振下叶片结构的动力响应试验系统.通过平板叶片振动响应的计算与试验对比分析,验证双向顺序耦合法适用于非共振状态以及共振状态的动力响应求解,数值仿真结果可以准确地反映振动响应的时域变化规律和频域特征.计算求得的振动位移和振动应力具有较好的计算精度,相对误差在40％以内,可以满足大多的工程计算需求.
- 叶片 /
- 顺序耦合法 /
- 试验验证 /
- 共振状态 /
- 动力响应
Abstract: An experimental system was erected to verify the precision of bidirectional sequential method of solving dynamical responses of blades caused by aerodynamic loads.The following results were obtained by comparison of calculation and experiment.Bidirectional sequential method is suitable for solving dynamical response of blades both in resonance state and in nonresonant state.The calculation results are correct in illuminating the vibration response both in time domain and in frequency domain.Bidirectional sequential method has a good calculation precision on solving vibration displacement and vibration stress whose relative errors are less than 40%.The method could satisfy the demands of most engineering problems.
- blade /
- sequential method /
- experimental verification /
- resonance state /

HTML

参考文献(12)

[1]	李其汉,王延荣,王建军.航空发动机叶片高循环疲劳失效研究[J].航空发动机,2003,29(4):16-18. LI Qihan,WANG Yanrong,WANG Jianjun.Investigation of high cycle fatigue failures for the aero engine blades[J].Aeroengine,2003,29(4):16-18.(in Chinese)
[2]	Srinivasan,A V.Flutter and resonant vibration characteristic of engine blades[J].Engineering for Gas Turbines and Power,1997,119(4):742-775.
[3]	William C S,Anthony N P.The consideration of high cycle fatigue in a turbine blade .AIAA Paper 2002-1537,2002.
[4]	谢远森,李意民,周忠宁,等.旋转预应力条件下的叶片流固耦合模态分析[J].噪声与振动控制,2009(4):34-37. XIE Yuansen,LI Yimin,ZHOU Zhongning,et al.Mode analysis of fluid-structure coupling blade under rotational and pre-stress state[J].Noise and Vibration Control,2009(4):34-37.(in Chinese)
[5]	Sanders A J,Fleeter S.Potential field interactions in a low-speed centrifugal compressor[J].Journal of Propulsion and Power,1998,14(6):925-933.
[6]	Kishore R,Patrick B L,Sanford F.High speed centrifugal compressor aeromechanics impeller unsteady aerodynamics .AIAA 2007-5020,2007.
[7]	Hirt C W,Amsden A A,Cook J L.An arbitrary Lagrangian-Eulerian computing method for all flow speeds[J].Journal of Computationnal Physics,1974,14(3):227-253.
[8]	Kishore R,Patrick B L,Sanford F.Finite element simulation of turbomachine blade row viscous interactions-vane vibratory stress predictions .AIAA 2004-0193,2004.
[9]	弓三伟,任丽芸,刘火星,等.汽轮机末级转子叶片流固耦合计算[J].热力透平,2007,36(3):154-157. GONG Sanwei,REN Liyun,LIU Huoxing,et al.Fluid solid interaction of rotor blade in last stage of steam turbine[J].Thermal Turbine,2007,36(3):154-157.(in Chinese)
[10]	Lau Y L,Leung R C K,So R M C.Vortex-induced vibration effect on fatigue life estimate of turbine blades[J].Journal of Sound and Vibration,2007,30(7):698-719.
[11]	张大义,马艳红,洪杰,等.气流激励下叶片振动响应分析方法[J].航空动力学报,2009,24(7):1523-1529. ZHANG Dayi,MA Yanhong,HONG Jie,et al.Dynamical response analysis on blades arisen by aerodynamic forces through sequential method[J].Journal of Aerospace Power,2009,24(7):1523-1529.(in Chinese)
[12]	马艳红,张大义,洪杰,等.气流激励下叶片的高周疲劳概率寿命预估技术[J].推进技术,2009,30(4):462-466. MA Yanhong,ZHANG Dayi,HONG Jie,et al.Prediction on high cycle life of blades using probability method[J].Journal of Propulsion Technology,2009,30(4):462-466.(in Chinese)
