弧形燕尾榫结构设计及形状优化
Structure design and shape optimization in arc dovetail
-
摘要: 为了设计弧形燕尾榫结构,对弧形燕尾型榫及叶片/榫头连接部位的三角过渡段进行研究,设计一种新的叶根型线.在上述工作基础上,建立了叶根型线与榫头顶面的尺寸约束关系,利用ANSYS软件建立叶片/榫头参数化模型,并开展榫头结构及叶根型线的优化设计,结果表明优化后的新结构叶背处的应力为827.11MPa,比原结构下降6.51%;新结构的叶片/榫头质量为0.86942kg,比原结构下降1.85%;新结构叶背喉部、叶盆喉部、叶身的应力分布比较均匀,三者之间应力梯度较小.综上所述,优化后的叶根型线结构比原叶片/榫头结构叶根型线结构更好.Abstract: In order to design the structure of arc dovetail,and analyze arc dovetail and triangle transition structure in the joint of blade and dovetail,a new type of blade profile was designed.Based on aforementioned work,size constraint relations between the blade profile and dovetail's top face were built,the blade and dovetail's parameter model was created using ANSYS software,and the blade profile and dovetail's structure were optimized.The results indicate that the optimized back stress of the new structure is 827.11 MPa,down by 6.51% than the original structure;the quality of new structure of the blade/dovetail is 0.869 42 kg,down by 1.85% than the original structure;the distribution of stress is more uniform and stress gradient is smaller among dorsal throat,leaves basin throat and leaves body.On the whole,the blade profile of optimal blade and dovetail structure is better as compared with that of initial blade and dovetail structure.
-
Key words:
- arc dovetail /
- triangle transition structure /
- blade profile /
- size constraint /
- optimization design
-
[1] 温卫东,高德平.榫头/榫槽接触问题边界元分析[J].航空动力学报,1992,7(2):117-120. WEN Weidong,GAO Deping.Analysis for contact problems with boundary element method in tenons/mortise[J].Journal of Aerospace Power,1992,7(2):117-120.(in Chinese) [2] 唐国安,丁海成.榫头-榫槽连接的盘/片结构接触问题计算[J].航空动力学报,1990,5(4):349-351. TANG Guoan,DING Haicheng.Contact problems calcul-ation for disc/blade in tenons/mortise joint[J].Journal of Aerospace Power,1990,5(4):349-351.(in Chinese) [3] 申秀丽,温卫东,高德平.接触问题形状优化的边界元法及其工程应用[J].航空动力学报,1997,12(2):113-116. SHEN Xiuli,WEN Weidong,GAO Deping.Shape optimiza-tion for contact problems with boundary element method[J].Journal of Aerospace Power,1997,12(2):113-116.(in Chinese) [4] 王迪,马利,朱金花,等.叶片榫头接触应力的求解研究[J]. 实验力学,2004,19(4):483-487. WANG Di,MA Li,ZHU Jinhua,et al.Study on solving contact stress on the blade rabbet[J].Journal of Experimental Mechanics,2004,19(4):483-487.(in Chinese) [5] 马刚.压气机燕尾型榫联接结构微动疲劳寿命研究 .南京:南京航空航天大学,2004. MA Gang.The research of the fretting fatigue life of dovetail joint in compressor .Nanjing:Nanjing University of Aeronautics and Astronautics,2004.(in Chinese) [6] 刘贵才,张栋,康德利,等.某发动机一级压气机叶片、轮盘断裂失效分析及预防[J].宇航材料工艺,2000(增刊):54-57. LIU Guicai,ZHANG Dong,KANG Deli,et al.Failure analysis and prevention for blade/disc of aero-engine[J].Aerospace Material & Technology,2000(Supplement):54-57.(in Chinese) [7] CUI Haitao,MA Haiquan,WEN Weidong.Reliability-based shape optimization of tenon/mortise in aero-engines with contact[J].Chinese Journal of Aeronnautics,2003,16(4):193-197. [8] 李立州,韩永志,王靖超.涡轮叶片榫头特征参数化型及优化 //中国航空学会第六届动力年会论文集.南京:中国航空学会动力专业分会,2006:495-498. [9] 刘廷毅,伊峰,张峻峰.航空发动机圆弧型榫头型面优化设计[J].南京航空航天大学报,2008,40(2):288-291. LIU Tingyi,YI Feng,ZHANG Junfeng.Optimization for arc contact face of swallow-tailed root[J].Journal of Nanjing University of Aeronautics and Astronautics.2008,40(2):288-291.(in Chinese) [10] 夏禹.涡轮叶片造型CAD系统研究 .西安:西北工业大学,2004. XIA Yu.The research of the development of turbine blade modeling CAD system .Xi'an:Northwestern Polytechnical University,2004.(in Chinese) [11] 王相平,徐鹤山.有限元计算中的叶片边界条件的选取[J].航空发动机,1998,9(4):43-46,57. WANG Xiangping,XU Heshan.Finite element method for the selection of blade boundary conditions[J].Aeroengine,1998,9(4):43-46,57.(in Chinese) [12] 博弈创作室.APDL参数化有限元分析技术及其应用实例[M].北京:中国水利水电出版社,2004:188-190.
