射流、旋流、出流共同作用下矩形通道换热特性

张宗卫; 朱惠人; 赵曙; 郭涛

射流、旋流、出流共同作用下矩形通道换热特性

西北工业大学动力与能源学院,西安 710072

基金项目: 国家重点基础研究发展计划(2007CB707701); 西北工业大学博士论文创新基金

计量
- 文章访问数: 2052
- HTML浏览量: 284
- PDF量: 19
- 被引次数: 0
出版历程
- 收稿日期: 2010-05-29
- 修回日期: 2010-10-28
- 刊出日期: 2011-06-28

Heat transfer characteristics in an internal coolant passage with crossflow-induced swirl, impingement and film cooling holes

School of Power and Energy, Northwestern Polytechnical University,Xi'an 710072,China

摘要

摘要: 在放大模型上详细研究了不同雷诺数和出流比下涡轮叶片内冷通道中冲击靶面、出流面和冲击侧面的换热特性.采用热色液晶瞬态测量技术测量通道内部各个面的传热系数,得到以下结论:靶面直接受到射流的第一次冲击,射流形成旋流对出流面进行第二次冲刷,对冲击侧面进行第三次冲刷;靶面受到冲击孔射流的直接冲击,因此换热最强;冲击侧面只受到旋流、横流影响,因此换热最弱;冲击和旋流是通道各个面换热强化的主要原因;换热随雷诺数的增大而增强.出流比对各个面的换热分布及大小也有一定影响.
- 涡轮 /
- 传热系数 /
- 冲击冷却 /
- 旋流 /
- 液晶
Abstract: The effects of Reynolds number and bleeding ratio on heat transfer of impingement target surface,bleeding-hole surface and impingement channel side surface were investigated in large-scaled test models for the cooling passages in gas turbine blade.A transient liquid crystal technique was used to measure the local heat transfer coefficients of inner surfaces of impingement channel.The results show that,on impingement channel inner surfaces,the main causation of high heat transfer coefficient is caused by the first,second and third impingement,respectively.The average heat transfer coefficient of impingement target surface is the highest on the same Reynolds number by the direct impingement.The average heat transfer coefficient of bleeding-hole surface is higher than channel side surface.The impingement and swirl play a primary role on the Nusselt number of the researched surfaces.The heat transfer was augmented distinctly with increase of Reynolds number.The bleeding ratio also affects the value and distributions of heat transfer coefficients of all inner surfaces.
- turbine /
- heat transfer coefficient /
- impingement cooling /
- swirl /

HTML

参考文献(15)

[1]	Han J C.Turbine blade cooling studies at Texas AM University:1980-2004[J].Journal of Thermophysics and Heat Transfer,2006,20(2):161-187.
[2]	曹玉璋,陶智,徐国强,等.航空发动机传热学[M].北京:北京航空航天大学出版社,2005.
[3]	Schiele R,Wittig S.Gas turbine heat transfer:past and future challenges[J].Journal of Propulsion and Power,2000,16(4):583-589.
[4]	Bunker R S.Gas turbine heat transfer:10 remaining hot gas path challenges .ASME GT2006-90002,2006.
[5]	Ekkad S V,Huang Y,Han J C.Detailed heat transfer distributions in two-pass square channels with rib turbulators and bleed holes[J].International Journal of Heat and Mass Transfer,1998,41(23):3781-3791.
[6]	张宗卫,朱惠人,杜小琴,等.带60°肋和出流孔的矩形通道端壁换热特性研究[J].西安交通大学学报,2010,44(5):116-119. ZHANG Zongwei,ZHU Huiren,DU Xiaoqin,et al.Investigations of endwall heat transfer in the rectangular passage with 60-degree ribs and suction holes[J].Journal of Xi'an Jiaotong University,2010,44(5):116-119.(in Chinese)
[7]	徐国强,李莉,丁水汀,等.带射流孔板矩形扰流柱通道内的壁面换热[J].推进技术,2009,30(1):14-17. XU Guoqiang,LI Li,DING Shuiting,et al.Heat transfer in rectangular pin-finned channel with perforated plate[J].Journal of Propulsion Technology,2009,30(1):14-17.(in Chinese)
[8]	毛军逵,缪国君,刘震雄.受限空间内斜向冲击凹柱面流场结构试验[J].航空动力学报,2010,25(1):11-17. MAO Junkui,MIU Guojun,LIU Zhenxiong.Experimental study of the flow structures of the concave surface with inclined impingement in limited space[J].Journal of Aerospace Power,2010,25(1):11-17.(in Chinese)
[9]	Glezer B,Moon H K,O'Connell T.Novel technique for the internal blade cooling .ASME GT1996-181,1996.
[10]	刘海涌,孔满昭,刘松龄,等.射流布局结构对短通道出流孔流场影响的实验[J].航空动力学报,2006,21(4):653-657. LIU Haiyong,KONG Manzhao,LIU Songling,et al.Effect of jet arrangement on the flow characteristics of the outlet hole in short confined channel[J].Journal of Aerospace Power,2006,21(4):653-657.(in Chinese)
[11]	Zhang Y M,Azad G M,Han J C,et al.Turbulent heat transfer enhancement and surface heating effect in square channels with wavy,and twisted tape inserts with interrupted ribs[J].Journal of Enhanced Heat Transfer,2000,7(1):35-49.
[12]	Mazumder A K,Saha S K.Enhancement of thermohydraulic performance of turbulent flow in rectangular and square ribbed ducts with twisted-tape inserts[J].Journal of Heat Transfer,2008,130(8):81702-81710.
[13]	杨通海,朱惠人,张丽,等.窄通道内冲击冷却局部换热特性的瞬态液晶测量[J].航空学报,2009,30(11):2031-2036. YANG Tonghai,ZHU Huiren,ZHANG Li,et al.Local heat transfer measurements in a narrow impingement channel by using transient liquid crystal technique[J].Acta Aeronautica et Astronautica Sinica,2009,30(11):2031-2036.(in Chinese)
[14]	苏福斌,朱惠人,郭涛,等.内冷通道带肋和出流孔壁面的换热研究[J].航空动力学报,2009,24(7):1500-1506. SU Fubin,ZHU Huiren,GUO Tao,et al.Heat transfer enhancement within an internal passage by combinations of ribs and suction holes[J].Journal of Aerospace Power,2009,24(7):1500-1506.(in Chinese)
[15]	Yan Y,Owen J M.Uncertainties in transient heat transfer measurements with liquid crystal[J].International Journal of Heat and Fluid Flow,2002,23(1):29-35.
