某涡扇发动机考虑级间引气的二维数值模拟

金东海; 桂幸民

某涡扇发动机考虑级间引气的二维数值模拟

北京航空航天大学能源与动力工程学院,北京 100191

基金项目: 国家自然科学基金(51006005, 50736007); 中央高校基本科研业务费专项资金(YWF-10-02-013); “凡舟”青年科研基金(20100401)

计量
- 文章访问数: 2030
- HTML浏览量: 1
- PDF量: 17
- 被引次数: 0
出版历程
- 收稿日期: 2010-09-28
- 修回日期: 2011-03-03
- 刊出日期: 2011-06-28

Two-dimensional numerical simulation of a turbofan engine with air bleeding in compressor

School of Jet Propulsion, Beijing University of Aeronautics and Astronautics,Beijing 100191,China

摘要

摘要: 针对采用S₂流面流场模拟软件(AES-S2),对某涡扇发动机风扇、压气机(考虑级间引气)和整机进行地面0km及高空21km低雷诺数工况下转速特性的评估和流场分析.AES-S2数值仿真模型由带有黏性项的二维欧拉方程、燃烧模型和损失模型构成;采用任意曲线坐标系,可保证复杂几何边界的计算精度;采用隐式高阶精度Godunov求解格式,数值稳定性高,可自动捕捉激波.仿真结果表明:AES-S2计算稳定性好,收敛速度快;风扇和压气机的计算精度高于整机;整机二维计算满足工程精度需求,可为部件研制和整机部件匹配提供性能参数依据.
- 数值模拟 /
- 涡扇发动机 /
- 风扇/压气机 /
- 二维 /
- 引气
Abstract: To assess the fan,compressor and whole engine performance of a turbofan engine on 0 km and 21 km operating conditions,considering air bleeding in compressor,an aero-engine S₂ stream-surface flow simulation software (AES-S2) was used.AES-S2 numerical simulation model consists of two-dimensional Euler equation,combustion model and loss model.A body fitted coordinate system was used to adapt the complex geometric boundaries.The implicit higher-order Godunov scheme has the characteristic of shock capturing and good numerical stability.Simulation results show that:AES-S2 runs with favorable stability and convergence speed;the simulation precision of fan and compressor is higher than that of engine;two-dimensional simulation of engine can provide a reliable matching performance with acceptable engineering precision.
- numerical simulation /
- turbofan engine /
- fan/compressor /

HTML

参考文献(12)

[1]	刘大响,程荣辉.世界航空动力技术的现状及发展动向[J].北京航空航天大学学报,2002,28(5):490-496. LIU Daxiang,CHENG Ronghui.Current status and development direction of aircraft power technology in the world[J].Journal of Beijing University of Aeronautics and Astronautics,2002,28(5):490-496.(in Chinese)
[2]	金捷.美国推进系统数值仿真(NPSS)计划综述[J].燃气涡轮试验与研究,2003,16(1):57-62. JIN Jie.A summary of numerical propulsion simulation system (NPSS) by NASA[J].Gas Turbine Experiment and Research,2003,16(1):57-62.(in Chinese)
[3]	李存杰.涡喷(涡扇)发动机的数值模拟和数值试验技术[J].飞航导弹,1995,11(1):56-60. LI Cunjie.Numerical simulation and numerical test technology of turbojet/turbofan engine[J].Winged Missiles Journal,1995,11(1):56-60.(in Chinese)
[4]	Wu C H.A general theory of three-dimensional flow in subsonic and supersonic turbomachines of axial-,radial-and mixed-flow types .NACA TN 2604,1952.
[5]	桂幸民.轴流风扇/压气机可控激波跨音级设计模型研究 .北京:北京航空航天大学,1993. GUI Xingmin.Research on the model of controllable shock wave in the design of transonic axial fan .Beijing:Beijing University of Aeronautics and Astronautics,1993.(in Chinese)
[6]	施发树,刘兴洲.多部件模型在全尺寸小型双函道涡扇发动机气流数值模拟中的应用[J].推进技术,1998,19(4):22-26. SHI Fashu,LIU Xingzhou.Multicomponent models in application to numerical simulation of a small full-sized by-pass turbofan engine[J].Journal of Propulsion Technology,1998,19(4):22-26.(in Chinese)
[7]	黄家骅,于廷臣,冯国泰.某小型涡扇发动机全流道准三维数值解法[J].航空发动机,2005,31(2):42-45. HUANG Jiahua,YU Tingchen,FENG Guotai.Quasi-3D numerical method for a small turbofan engine flow passage[J].Aeroengine,2005,31(2):42-45.(in Chinese)
[8]	曹志鹏,刘大响,桂幸民,等.某小型涡喷发动机二维数值仿真[J].航空动力学报,2009,24(2):339-444. CAO Zhipeng,LIU Daxiang,GUI Xingmin,et al.Two dimensional numerical simulation of small turbojet engine[J].Journal of Aerospace Power,2009,24(2):339-444.(in Chinese)
[9]	曹志鹏.某小型涡喷发动机整机二维数值仿真研究 .北京:北京航空航空大学,2008. CAO Zhipeng.Two dimensional numerical simulation of small turbojet engine .Beijing:Beijing University of Aeronautics and Astronautic,2008.(in Chinese)
[10]	卫岗,李清华,何谦.发动机整机仿真软件在工程设计中的应用 .北京:中国航空学会第一届航空发动机数值仿真与数字化设计交流会,2008.
[11]	金东海.某发动机风扇/压气机/整机性能特性数值仿真研究 .北京:北京航空航空大学,2009. JIN Donghai.Numerical investigation of aerodynamic performance of a fan/compressor/engine .Beijing:Beijing University of Aeronautics and Astronautics,2009.(in Chinese)
[12]	Nigmatullin R,Ivanov M.The mathematical models of flow passage for gas turbine engines and their components .AGARD Lecture Series LS198,1994(4):4-1,4-28.
