非轴对称端壁下高负荷压气机叶栅二次流动分析
Secondary flow analysis for non-axisymmetric endwall on the high-load compressor cascade
-
摘要: 探讨了高负荷压气机叶栅中应用非轴对称端壁的有效性.首先利用NUMECA/Design3D优化软件包来完成了对端壁的优化,然后推导并建立了高负荷压气机叶栅出口含全部掺混损失的二次流损失的计算方法,最后在设计攻角和非设计攻角下对轴对称端壁和非轴对称端壁结构的高负荷压气机叶栅内部及出口流场进行了详细的分析.分析结果表明:在设计攻角和非设计攻角下采用非轴对称端壁均能改变端壁附近载荷分布、降低叶片通道的二次流动损失;在设计攻角下使叶栅周向质量平均总压损失减少约为9.4%,在非设计攻角(±3°)下分别减损7.7%和11.8%;当非轴对称端壁幅值为4%叶高时,二次流动损失最小.Abstract: The effectiveness of a non-axisymmetric endwall on a high-load compressor cascade was discussed.First of all,the trigonometric function was used to complete non-axisymmetric endwall profiling.Then the method of calculating the mixed-out secondary loss for the compressor cascade was established.Finally,the detailed numerical simulations were conducted on the cascade flow field with non-axisymmetric hub endwall.Numerical results show that with the non-axisymmetric hub endwall,the loading distribution near the endwall would be changed and the secondary loss would be reduced in both the design and off-design condition.It has been indicated that the mass average total pressure loss can decrease by 9.4% in the design and by 7.7% and 11.8% in the off-design condition(±3°),respectively.When the non-axisymmetric contour height equals to be 4% of blade span,the secondary flow loss should be the lowest.
-
Key words:
- high-load compressor cascade /
- non-axisymmetric endwall /
-
[1] Howell A R.Fluid dynamics of axial compressors[J] .Proceedings of the Institution of Mechanical Engineers,1945,153:441-452. [2] Rose M G.Non-axisymmetric endwall profiling in the HP NGVs of an axial flow gas turbine .ASME Paper 94-GT-294,1994. [3] Hartland J,Harvey N M, Seaman P,et al.Improveing the efficiency of the turbine using non-anxiymmetric end walls Part Ⅱ:exprerimental validation .ASME Paper GT-2002-30337,2002. [4] Harvey N W,Rose M G,Taylor M D,et al.Non-axisymmetric turbine endwall design Part Ⅰ :three dimensional linear design system[J].Journal of Turbomachinery,2000,122(2):278-285. [5] Hartland J C,Gregory-Smith D G,Harvey N W,et al.Non-axisymmetric endwall design PartⅡ :experimental validation[J].Journal of Turbomachinery,2000,122(2):286-293. [6] Hoeger M,Cardamone P,Fottner L.Influence of endwall contouring on the transonic flow in a compressor blade .ASME Paper GT-2002-30440,2002. [7] Torre D,Vzquez R,De la Rosa Blanco E,et al.A new alternative for reduction of secondary flows in low pressure turbines .ASME Paper GT-2006-91002,2006. [8] Harvey N W.Some effects of non-axisymmetric endwall profiling on axial flow compressor aerodynamics Part Ⅰ: linear cascade investigation .ASME Paper GT-2008-50990,2008. [9] Harvey N W,Offord T P.Some effects of non-axisymmetric endwall profiling on axial flow compressor aero-dynamics Part Ⅰ:multi-stage HPC CFD study .ASME Paper GT-2008-50991,2008. [10] 刘波,管继伟,陈云永,等.用端壁造型减小涡轮叶栅二次流损失的数值研究[J].推进技术,2008,29(3):355-359. LIU Bo,GUAN Jiwei,CHEN Yunyong,et al.Numerical investigation for effect of non-axisymmetric endwall profiling on secondary flow in turbine cascade[J].Journal of Propulsion Technology,2008,29(3):355-359.(in Chinese) [11] 卢家玲,楚武利,胡书珍,等.端壁造型技术在 亚声轴流压气机级中的应用[J].航空动力学报,2009,24(5):1101-1107. LU Jialing,CHU Wuli,HU Shuzhen,et al.Application of endwall contour on subsonic axial flow compressor stage[J].Journal of Aerospace Power,2009,24(5):1101-1107.(in Chinese) [12] 胡书珍,卢新根,张宏武,等.亚音速轴流压气机转子非轴对称轮毂端壁的数值研究[J].工程热物理学报,2009,30(3):385-388. HU Shuzhen,LU Xingen,ZHANG Hongwu,et al.Numerical investigation on a subsonic axial-flow compressor rotor with the implementation of non-axisymmetric hub endwall[J].Journal of Engineering Thermophysics,2009,30(3):385-388.(in Chinese)
