基于流量法的齿轮传动涡扇发动机动态建模

童万军; 唐世建

基于流量法的齿轮传动涡扇发动机动态建模

中国航空工业集团公司中国燃气涡轮研究院,成都 610500

计量
- 文章访问数: 2906
- HTML浏览量: 161
- PDF量: 30
- 被引次数: 0
出版历程
- 收稿日期: 2010-05-12
- 修回日期: 2010-10-17
- 刊出日期: 2011-06-28

Geared turbofan engine transient modeling research based on CMF method

Gas Turbine Establishment of China, Aviation Industry Corporation of China,Chengdu 610500,China

摘要

摘要: 从热力学、气体动力学和发动机基本原理出发,对基于流量法的齿轮传动涡扇发动机动态性能建模技术展开了研究,并推导出了基于流量法的齿轮传动涡扇发动机动态数学模型的求解方程组.基于该模型方程组,利用C++面向对象编程语言,建立起了某齿轮传动涡扇发动机的动态模型.该发动机动态模型与著名的商业化发动机性能计算软件Gasturb 10进行的比对显示:该模型的运算结果与Gasturb 10的运算结果具有良好的一致性,最大误差不大于1.5%.证明了基于流量法的齿轮传动涡扇发动机动态数学模型求解方程组的正确性和适用性.
- 流量法 /
- 齿轮传动涡扇发动机 /
- 涡扇发动机 /
- 大涵道比发动机 /
- 动态模型 /
- 建模方法
Abstract: On the basis of thermodynamics,gas dynamics and gas turbine principles,a detailed research on how to model the transient performance of a geared turbofan engine was performed,and the relevant solver equations were deduced simultaneously by employing constant mass flow (CMF) method in the paper.A geared turbofan engine transient model was successfully coded by means of employing the solver equations and C++ programming language.On the comparable basis,the calculation results have quite remarkable consistency with those results calculated by Gasturb 10,a famous commercial software in aero-engine performance simulation,with maximum errors within 1.5%.Hence,these consequences show the correctness and applicability of the solver equations.
- constant mass flow(CMF) method /
- geared turbofan engine /

HTML

参考文献(12)

[1]	李杰.齿轮传动涡轮风扇(GTF)发动机先进技术综述[J].航空发动机,2009,35(4):54-57. LI Jie.Overview of advanced technology for geared tuebofan engine(GFT)[J].Aeroengine,2009,35(4):54-57.(in Chinese)
[2]	戈尔别格.航空燃气涡轮发动机的控制方法与动态特性的数学模拟[M].程心健,译.无锡:中国航空动力控制系统研究所,1996.
[3]	Holman J P.Thermodynamics[M].3rd ed.New York:McGraw-Hill,1980.
[4]	Cambel A B,Jennings B H.Gas dynamics[M].New York:McGraw-Hill,1958.
[5]	White F M.Fluid mechanics[M].5th ed.New York:McGraw-Hill Education ISE Editions,2003.
[6]	Saravanamuttoo H I H.Gas turbine theory[M].5th ed.Harlow:Prentice Hall,2001.
[7]	Walsh P P,Fletcher P.Gas turbine performance[M].2nd ed.Oxford:Blackwell Science,2004.
[8]	Society of Automotive Engineers.Gas turbine engine performance station identification and nomenclature[M].Warrendale,PA:Aerospace Recommended Practice,ARP 755A,SAE,1974.
[9]	唐世建,童万军,钟小红,等,航空发动机核心机建模技术研究与应用[J].航空发动机,2007,33(3):41-44. TANG Shijian,TONG Wanjun,ZHONG Xiaohong,et al.Research and application of modeling technology on core engine[J].Aeroengine,2007,33(3):41-44.(in Chinese)
[10]	唐世建,李健民,王戈一,等,涡扇发动机模型计算程序[J].燃气涡轮试验与研究,2000,13(1):45-52.
[11]	华清.某型涡扇发动机全包线实时仿真模型[J].航空发动机,2002,28(1):47-52. HUA Qing.A realtime simulation model of a typical turbofan engine in full flight evelope[J].Aeroengine,2002,28(1):47-52.(in Chinese)
[12]	聂恰耶夫.航空动力装置控制规律与特性[M],单凤桐,程振海,译.北京:国防工业出版社,1999.
