某型无人直升机活塞式电喷发动机转速控制设计及试验

曾国贵; 廖智麟; 阚兆成

某型无人直升机活塞式电喷发动机转速控制设计及试验

中国航空工业集团公司中国直升机设计研究所,江西景德镇 333001

计量
- 文章访问数: 2054
- HTML浏览量: 235
- PDF量: 24
- 被引次数: 0
出版历程
- 收稿日期: 2010-05-11
- 修回日期: 2010-11-13
- 刊出日期: 2011-06-28

Speed control design and test for piston EFI engine of unmanned helicopter

China Helicopter Research and Development Institute, Aviation Industry Corporation of China,Jingdezhen Jiangxi 333001,China

摘要

摘要: 针对某型无人直升机活塞式电喷发动机的特性,结合无人直升机不同阶段对旋翼转速的要求,采用转速前馈与反馈比例控制模式对地面暖车转速进行控制.采用了转速前馈、负载前馈、转速变参与反馈PID(比例、积分、微分)控制结合的控制模式实现慢车转速到额定转速的有效过渡.额定工作转速的控制采用了转速前馈、负载前馈、自动配平、转速差前馈与反馈PID控制相结合的复合型控制策略,以保证发动机在额定工作状态下转速波动误差尽量减小,实现无人直升机动力关键部分的控制.通过地面试车台发动机开车试验表明,所采用的复合型控制策略能有效实现发动机恒转速控制.
- 无人直升机 /
- 电喷(EFI)发动机 /
- 电子控制单元(ECU) /
- 复合控制 /
- 发动机控制
Abstract: The engine speed in warm condition was controlled by feed-forward and proportional feedback according to the characteristics of electronic fuel injection (EFI) engine and the requirements of engine speed at different phases in unmanned helicopter.The smooth transition from low to normal speed condition was achieved by speed feed-forward,load feed-forward,speed parameter model and feedback PID(proportion,integration,differential).The normal speed was controlled by using the complex scheme of feed-forward,load-forward,auto-trim,difference of rotational speed feed-forward and PID feedback.It proves that the complex control scheme is effective to constant engine speed control by use of the engine ground test at drive simulation platform.
- unmanned helicopter /
- electric fuel injection(EFI) engine /

HTML

参考文献(12)

[1]	彭昭勇.无人直升机飞行控制技术研究 .南京:南京航空航天大学,2000. PENG Zhaoyong.Study of unmanned helicopter flight control technology .Nanjing:Nanjing University of Aeronautics and Astronautics,2000.(in Chinese)
[2]	彭昌普.汽油机与无人直升机的动力匹配技术研究 .南京:南京航空航天大学,1998. PENG Changpu.Study of gasoline power matching with the unmanned helicopter technology .Nanjing:Nanjing University of Aeronautics and Astronautics,1998.(in Chinese)
[3]	李汝辉,吴一黄.活塞式航空动力装置[M].北京:北京航空航天大学出版社,2008.
[4]	张昭昭.电喷燃油喷射系统的研究 .辽宁阜新:辽宁工程技术大学,2005. ZHANG Zhaozhao.Study of electric fuel injection system .Fuxin Liaoning:Liaoning Technical University,2005.(in Chinese)
[5]	李国良,于秀敏,宋秋红,等.二冲程汽油机电控燃油喷射研究[J].农业机械学报,2000,31(6):11-12,16. LI Guoliang,YU Xiumin,SONG Qiuhong,et al.Study on electronically controlled fuel injection for a two stroke cycle gasoline engine[J].Transactions of the Chinese Society of Agricultural Machinery,2000,31(6):11-12,16.(in Chinese)
[6]	魏强.二冲程汽油机电控燃油喷射系统的研究与开发 .长春:吉林工业大学,1997. WEI Qiang.Study and development of two-stroke gasoline electronic fuel injection system .Changchun:Jilin University of Technology,1997.(in Chinese)
[7]	杨振祥,阮红霞.小型无人直升机动力装置活塞发动机的动态效应[J].直升机技术,2006,146(2):32-35. YANG Zhenxiang,RUAN Hongxia.The dynamic effect for piston engine on mini-unmanned helicopter[J].Helicopter Technique,2006,146(2):32-35.(in Chinese)
[8]	何元磊,卢利斌,王祥,等.某型无人机发动机动力学建模与仿真[J].航空兵器,2007(1):28-31. HE Yuanlei,LU Libin,WANG Xiang,et al.Engine dynamics modeling and simulation for a type of UAV[J].Aero Weaponry,2007(1):28-31.(in Chinese)
[9]	王小青,黄一敏,杨一栋.小型无人直升机活塞式电喷发动机冲速段的控制策略[J].航空动力学报,2007,22(6):928-932. WANG Xianqing,HUANG Yimin,YANG Yidong.Control strategy for piston ECU engine in overrunning of a small-size unmanned helicopter[J].Journal of Aerospace Power,2007,22(6):928-932.(in Chinese)
[10]	冀树德,张辉,贾祯,等.ECU控制性能的动态试验研究[J].车用发动机,2008(176):106-109. JI Shude,ZHANG Hui,JIA Zhen,et al.The research of dynamic test on ECU controlling performance[J].Vehicle Engine,2008(176):106-109.(in Chinese)
[11]	庞海洋,段文龙.发动机试验中伺服控制系统抗干扰技术研究[J].固体火箭发动机,2000,23(1):74-78. PANG Haiyang,DUAN Wenlong.Anti-interference of servo-control system in solid rocket motor testing[J].Journal of Solid Rocket Technology,2000,23(1):74-78.(in Chinese)
[12]	邱军芳,雷勇,柳共青.工程数据库在某型发动机试车中的应用[J].航空动力学报,2003,18(3):432-435. QIU Junfang,LEI Yong,LIU Gongqing.The application of engineering database in aeroengine test[J].Journal of Aerospace Power,2003,18(3):432-435.(in Chinese)
