基于混合灵敏度的航空发动机切换控制系统设计
Switching control system design for aero-engine based on mixed sensitivity
-
摘要: 针对航空发动机工作安全边界,提出了一种基于切换控制的航空发动机控制系统设计方法.给出了切换控制策略的设计思路及切换稳定性的条件.给出基于混合灵敏度的航空发动机多回路切换鲁棒控制器设计方法,并构造了线性矩阵不等式.通过基于计算得到的控制器参数仿真表明,采用该切换方式相比于Min/Max切换方式消除了积分饱和在切换中延迟影响,提高发动机的动态响应能力及鲁棒性,同时可以保证切换的稳定性.Abstract: A systematic framework of switching controllers design for aero engines according to the safe boundaries was presented.Firstly,an approach to design the switching strategy and stability conditions were proposed.Secondly,based on mixed sensitivity robust control and switching control theory,by constructing linear matrix inequalities,a sufficient condition was proposed in terms of matrix inequalities.The simulation based on calculated controllers' parameters shows that using the using switching strategy can eliminate the delay effect caused by integrator wind-up,and can improve the dynamic performance of the engine control system,and guarantee the stability in some peculiar occasions.
-
Key words:
- aero-engine /
- switching control /
- mixed sensitivity /
-
[1] 樊思齐,李华聪,樊丁,等.航空推进系统控制(下册)[M]. 西安:西北工业大学出版社,2008. [2] Lee J K,Kim C,Yang S et al.Measurement of a gas turbine engine by fuel ppiking test[J].AIAA 2005-810,2005. [3] Moore F K,Greitzer E M.A theory of post-stall transients in a axial compressor systems Part I:development of equations[J].Journal of Engineering for Gas Turbines and Power,1986,108(1):68-76. [4] 王小艳,赵虹,罗雄麟.叶轮压缩系统喘振的主动控制[J].动力工程,2006,26(6):421-425. WANG Xiaoyan,ZHAO Hong,LUO Xionglin.Active surging control of turbo-compressor systems[J].Journal of Power Engineering,2006,26(6):421-425.(in Chinese) [5] 邢家瑞,张绍基,姜彩虹,等.昆仑发动机发射武器防喘控制系统的研制[J].航空动力学报,2004,19(6):462-465. XING Jiarui,ZHANG Shaoji,JIANG Caihong,et al.Development of a surge preventive control system applied to the Kunlun aeroengine[J].Journal of Aerospace Power,2004,19(6):462-465.(in Chinese) [6] Kura R,White R C.Surge avoidance in gas compression systems[J].Journal of Turbomachinery,2004,126(4):501-506. [7] Epstein A H,Ffowcs-Williams J E,Greitzer E M.Active suppression of compressor instabilities[J].AIAA-86-1994,1986. [8] 刘晓锋,隋岩峰,何保成,等.涡扇发动机多回路切换系统稳定性分析[J].航空动力学报,2006,21(3):197-201.(in Chinese) LIU Xiaofeng,SUI Yanfeng,HE Baocheng,et al.Switching stability analysis of multi-control loops for turbofan engine[J].Journal of Aerospace Power,2006,21(3):197-201.(in Chinese) [9] 黄琳.稳定性与鲁棒性的理论基础[M].北京:科学出版社,2003. [10] Liberzon D,Morse A S.Basic problems in stability and design of switched systems[J].Control Systems Magazine,1999,19(5):59-70. [11] 周克敏,Doyle,Glover.鲁棒与最优控制[M].毛剑琴,钟宜生,林岩,译.北京:国防工业出版社,2002. [12] Boyd S,Ghaoui L E,Feron E,et al.Linear matrix inequilities in system and control theory[M].Philadelphia:SIAM,1994. [13] 何保成.弹用涡扇发动机控制系统故障仿真研究 .哈尔滨:哈尔滨工业大学,2000. HE Baocheng.Research on fault simulations for missile turbofan engine .Harbin:Harbin Institute of Technology,2000.(in Chinese)
