基于UIO的航空发动机控制系统传感器故障诊断

覃道亮; 何皑; 孔祥兴; 王曦

基于UIO的航空发动机控制系统传感器故障诊断

北京航空航天大学能源与动力工程学院,北京 100191

基金项目: 航空科学基金(2009ZB51); 航空推进技术验证计划

计量
- 文章访问数: 1991
- HTML浏览量: 185
- PDF量: 22
- 被引次数: 0
出版历程
- 收稿日期: 2010-05-06
- 修回日期: 2010-09-07
- 刊出日期: 2011-06-28

UIO-based sensor fault diagnosis for aero-engine control systems

School of Jet Propulsion, Beijing University of Aeronautics and Astronautics,Beijing 100191,China

摘要

摘要: 研究了航空发动机控制系统传感器鲁棒故障检测与隔离问题,提出了一种克服不同干扰对控制系统诊断性能影响的方法.应用未知输入观测器(unknown input observer,简称UIO)理论来解耦航空发动机动态系统干扰,并针对控制系统传感器设计一族UIO,提取出一系列的传感器残差特征数据,通过分析残差队列的幅值特性,实现航空发动机控制系统传感器故障诊断.在高斯白噪声、模型工作点变化和非高斯噪声三类干扰下的数字仿真结果表明,不管何种干扰,UIO诊断方法均能检测和隔离出传感器故障,在诊断鲁棒性方面,要优于Kalman滤波器诊断算法.
- 未知输入观测器(UIO) /
- 航空发动机控制 /
- 传感器故障 /
- 故障诊断 /
- 残差生成
Abstract: The problem of sensor fault detection and isolation for aero-engine control systems was studied and an approach to overcome the impact of various disturbances on the performance in diagnosis of the control systems was proposed in this paper.This approach applied unknown input observer (UIO) theory to decouple the disturbance in the aero-engine dynamic model.Then,a bank of UIOs for the sensors in the control system were designed,and a series of residual features for the control system's sensors were extracted.By analyzing the characteristics of magnitudes in the queue of residuals,this paper accomplished the sensor-fault detection and isolation.Numerical simulation results with the disturbances of Gaussian white noise,a moderate change in the operating point of the engine,and non-Gaussian noise show that,the UIO-based method can effectively detect and isolate sensor faults irrespective of the class of the system disturbance,and outperform the Kalman filter-based algorithm in term of diagnosis robustness.
- unknown input observer (UIO) /
- aero-engine control /
- sensor fault /

HTML

参考文献(16)

[1]	江传尚,樊丁,马冲.小波网络在某型航空发动机故障诊断中的应用[J].航空动力学报,2009,24(4):892-895. JIANG Chuanshang,FAN Ding,MA Chong.Application of the wavelet network in fault diagnosis for some kind of aeroengine[J].Journal of Aerospace Power,2009,24(4):892-895.(in Chinese)
[2]	侯胜利,李应红,尉询楷.基于遗传规划和线性鉴别分析的故障特征提取模型及其应用[J].推进技术,2006,27(3):270-275. HOU Shengli,LI Yinghong,WEI Xunkai.Feature extraction based on genetic programming and linear discriminant analysis for fault diagnosis and its application[J].Journal of Propulsion Technology,2006,27(3):270-275.(in Chinese)
[3]	任海峰,胡小平,吴建军.应用独立分量分析提取液体火箭发动机的故障特征[J].推进技术,2004,25(6):481-490. REN Haifeng,HU Xiaoping,WU Jianjun.Independent component analysis for the fault features of liquid propellant rocket engine[J].Journal of Propulsion Technology,2004,25(6):481-490.(in Chinese)
[4]	胡金海,谢寿生,陈卫,等.基于核函数主元分析的航空发动机故障检测方法[J].推进技术,2008,29(1):79-83. HU Jinhai,XIE Shousheng,CHEN Wei,et al.An aeroengine fault detection method based on kernel principal component analysis[J].Journal of Propulsion Technology,2008,29(1):79-83.(in Chinese)
[5]	徐启华,师军.基于支持向量机的航空发动机故障诊断[J].航空动力学报,2005,20(2):298-302. XU Qihua,SHI Jun.Aeroengine fault diagnosis based on support vector machine[J].Journal of Aerospace Power,2005,20(2):298-302.(in Chinese)
[6]	姚华,单贵平,孙健国.基于卡尔曼滤波器及神经网络的发动机故障诊断[J].航空动力学报,2008,23(6):1111-1117. YAO Hua,SHAN Guiping,SUN Jianguo.Fault diagnosis for gas turbine engines based on Kalman filter and neural networks[J].Journal of Aerospace Power,2008,23(6):1111-1117.(in Chinese)
[7]	Chen J,Patton R J.Robust model-based fault diagnosis for dynamic systems[M].Norwell,MA,USA:Kluwer Academic Publishers,1999.
[8]	Patton R J,Frank P M,Clark R N.Issues of fault diagnosis for dynamic systems[M].London:Springer,2000.
[9]	Kobayashi T.Aircraft engine sensor/actuator/component fault diagnosis using a bank of Kalman filters .Glenn Research Center,NASA CR-2003-212298,2003.
[10]	Al-Hamdan Q Z,Ebaid M.Modeling and simulation of a gas turbine engine for power generation[J].Journal of Engineering for Gas Turbines and Power,2006,128(2):302-311.
[11]	Martin S,Wallace I,Bates D G.Development and validation of a civil aircraft engine simulation model for advanced controller design[J].Journal of Engineering for Gas Turbines and Power,2008,130(5):051601(15 pages).
[12]	Krzeminski S,Kaczorek T.Perfect reduced-order unknown-input observer for standard systems[J].Bulletin of the Polish Academy of Sciences Technical Sciences,2004,52(2):104-107.
[13]	Hui S,Zak S.Observer design for systems with unknown inputs[J].International Journal of Applied Mathematics and Computational Science,2005,15(4):431-446.
[14]	Frank P M.Fault diagnosis in dynamic systems using analytical and knowledge-based redundancy:a survey and some new results[J].Automatica,1990,26(3):459-474.
[15]	Hofbauer W,Dolovai P,Jrgl H,et al.LQG/LTR controller design for a gas engine //Proceedings of 2006 IEEE International Symposium on Industrial Electronics.Montreal,Canada:IEEE,2006:1631-1636.
[16]	Perhinschi M G,Napolitano M R,Campa G,et al.An adaptive threshold approach for the design of an actuator failure detection and identification scheme[J].IEEE Transactions on Control Systems Technology,2006,14(3):519-525.
