前置肋片对凹槽火焰稳定器混合特性的影响

金劲睿; 刘玉英; 洪燕

前置肋片对凹槽火焰稳定器混合特性的影响

北京航空航天大学能源与动力工程学院, 北京 100191

基金项目: 航天科技创新基金(CASC200903)

计量
- 文章访问数: 1593
- HTML浏览量: 92
- PDF量: 14
- 被引次数: 0
出版历程
- 收稿日期: 2011-01-06
- 修回日期: 2011-05-10
- 刊出日期: 2011-12-28

Effects of injection fin on flow and mixing characteristics of cavity flame holder

School of Jet Propulsion, Beijing University of Aeronautics and Astronautics, Beijing 100191, China

摘要

摘要: 将前置肋片结构应用于超声速凹槽火焰稳定器中,数值模拟研究了前置肋片对凹槽火焰稳定器混合特性的影响.结果表明:与传统结构相比,在凹槽稳定器中加入前置肋片,能减小总压损失,增大凹槽内外喷口的穿透深度,并获得更为均匀燃料分布,有利于燃烧组织.
- 超声速燃烧 /
- 前置肋片 /
- 凹槽火焰稳定器 /
- 混合增强 /
- 数值模拟
Abstract: Effects of injection fin in the supersonic cavity flame-holder were studied numerically.Both pressure loss and mixing enhancement effects were investigated.The results suggest that compared with the traditional structure,the cavity with injection fin induce less pressure loss,eularges penetration depth of the injections,and achieves a more appropriate fuel distribution.
- supersonic combustion /
- injection fin /
- cavity flame-holder /
- mixing enhancement /
- numerical simulation

HTML

参考文献(15)

[1]	贺武生.超燃冲压发动机研究综述[J].火箭推进,2005,31(1):29-32. HE Wusheng.Review of scramjet engine development[J]. Journal of Rocket Propulsion,2005,31(1):29-32.(in Chinese)
[2]	Roudakov A S,Schikhmann Y,Semenov V,et al.Flight testing of an axisymmetric scramjet-Russian recent advances[R].ONERA-TAP-95-81,1995.
[3]	Vinagradov V,Kobigsky S A,Petrov M D.Experimental investigation of kerosene fuel combustion in supersonic flow[J].Journal of Propulsion and Power,1995,11(1):130-134.
[4]	Ben-Yakar A,Hanson R K.Cavity flame-holders for ignition and flame stabilization in scramjets:an overview[J].Journal of Propulsion and Power,2001,17(4):869-877.
[5]	Gruber M R,Baurle R A,Mathur T.Fundamental studies of cavity-based flame holder concepts for supersonic combustors[J].Journal of Propulsion and Power,2001,17(1):146-153.
[6]	刘世杰,潘余,刘卫东.超燃冲压发动机支板喷射燃料的燃烧过程试验[J].航空动力学报,2009,24(1):55-59. LIU Shijie,PAN Yu,LIU Weidong.Experimental study on the combustion and flow process in a scramjet with strut injector[J].Journal of Aerospace Power,2009,24(1):55-59.(in Chinese)
[7]	汪洪波,孙明波,吴海燕,等.超声速燃烧凹腔质量交换特性的混合RANS/LES模拟[J].航空动力学报,2010,25(1):41-46. WANG Hongbo,SUN Mingbo,WU Haiyan,et al.Hybrid RANS/LES simulation of mass exchange characteristics of cavity for supersonic combustion[J].Journal of Aerospace Power,2010,25(1):41-46.(in Chinese)
[8]	Freeborn A B,King P I,Gruber M R.Swept-leading-edge pylon effects on a scramjet pylon-cavity flame holder flow-field [J].Journal of Propulsion and Power,2009,25(3):571-582.
[9]	Hsu K Y,Carter C D,Gruber M R,et al.Experimental study of cavity-strut combustion in supersonic flow[R].AIAA-2007-5394,2007.
[10]	Jeong E J,O''''''''Byme S,Jeung I S,et al.Investigation of supersonic combustion with angled injection in a cavity-based combustor[J].Journal of Propulsion and Power,2008,24(6):1258-1268.
[11]	孙明波,耿辉,梁剑寒,等.超声速来流稳焰凹腔上游气体燃料横向喷注的流动混合特征[J].推进技术,2008,29(3):306-311. SUN Mingbo,GENG Hui,LIANG Jianhan,et al.Mixing characteristics of gaseous fuel injection upstream of a flame holding cavity in supersonic flow[J].Journal of Propulsion Technology,2008,29(3):306-311.(in Chinese)
[12]	耿辉.超音速燃烧室中凹腔上游横向喷注燃料的流动、混合与燃烧特性研究[D].长沙:国防科技大学,2007. GENG Hui.Investigation of flow,mixing and combustion properties of transverse fuel injection upstream of the cavity in a supersonic combustor[D].Changsha:Graduate School of National University of Defense Technology,2007.(in Chinese)
[13]	Aguilera C,Pang B,Winkelmann A,et al.Supersonic mixing enhancement and optimization using fin-guided fuel injection[R].AIAA-2010-1526,2010.
[14]	Gerlinger P,Stoll P,Kindler M,et.al.Numerical investigation of mixing and combustion enhancement in supersonic combustors by strut induced streamwise vorticity[J].Aerospace Science and Technology,2008,12(2):159-168.
[15]	Segal C,Michael J R.The scramjet engine:prcesses and characteristics[M].New York:Cambridge University Press,2009.
