基于VOF方法分析离心式喷嘴结构参数对性能影响

刘娟; 孙明波; 李清廉; 王振国

基于VOF方法分析离心式喷嘴结构参数对性能影响

国防科学技术大学航天与材料工程学院, 长沙 410073

基金项目: 国家自然科学基金(10802095)

计量
- 文章访问数: 1812
- HTML浏览量: 6
- PDF量: 9
- 被引次数: 0
出版历程
- 收稿日期: 2011-05-04
- 修回日期: 2011-11-24
- 刊出日期: 2011-12-28

Analysis of geometric parameters influence on pressure swirl injector performance based on VOF interface tracking method

College of Aerospace and Material Engineering, National University of Defense Technology, Changsha 410073, China

摘要

摘要: 基于两相界面追踪流体体积(volume of fluid,简称VOF)方法模拟了离心式喷嘴内部的流动过程,在数值方法可靠性验证基础上,得到了15个喷嘴构型的流量系数、液膜厚度以及雾化锥角.定义无量纲影响因子η,比较喷嘴结构参数对喷嘴性能的影响程度.除了喷嘴直径和旋流室直径外,重点研究了出口扩张角、等直段长径比等结构参数的影响,通过与试验相对比,综合以往经验公式,得到如下结论:增大旋流室长度,能够增大雾化锥角;在喷嘴出口增加扩张角,能够显著地减小液膜厚度,减小雾化锥角;增大切向口距喷嘴顶部距离,能够改善喷嘴性能;切向口个数和等直段长度对喷嘴性能影响不大.该工作为下一步优化喷嘴构型打下了基础.
- 流体体积 /
- 离心式喷嘴 /
- 流量系数 /
- 液膜厚度 /
- 雾化锥角
Abstract: Interface tracking method volume of fluid (VOF) was used to simulate the flow process in pressure-swirl injector.Three target values including discharge coefficient,film thickness and spray cone angle were obtained after validating the reliability of numerical method.Non-dimensional influence factor η was defined to evaluate the influence of the 15 geometry parameters.The focus is on the geometry parameters which have not been researched much before,such as divergent angle,the length of swirl chamber and so on.The extention of the length of swirl chamber increases spray cone angle.Divergent angle at the injector exit decreases sheet thickness and increases cone angle remarkably.Increasing the distance between the injector and the top wall enhances injector performance.The number of tangent inlet and the length of central post dont not have much to do with the injector performance.What have been done in this paper helps to optimize the injector geometry.
- volume of fluid (VOF) /
- pressure swirl injector /
- discharge coefficient /
- sheet thickness /
- spray cone angle

HTML

参考文献(17)

[1]	朱宁昌,刘国球.液体火箭发动机设计(上)[M].北京:宇航出版社,1994.
[2]	Novikov I I.Atomization of liquids by centrifugal nozzles[J].Journal of Technical Physics,1948,18(3):345-354.
[3]	Taylor G I.The boundary layer in the converging nozzle of a swirl atomizer[J].The Quarterly Journal of Mechanics and Applied Mathematics,1949,3(2):129-139.
[4]	Dombrowski N,Hasson D.The flow characteristics of swirl spray pressure nozzles with low viscosity liquids[J].Jouranl of AICHE,1969,15(4):604-611.
[5]	Rizk N K,Lefebvre A H.Internal flow characteristics of simplex swirl atomizers[J].Journal of Propulsion and Power,1985,1(3):193-199.
[6]	Rizk N K,Lefebvre A H.Spray characteristics of simplex swirl atomizers[R].Easton City,PA,United States:Purdue University Lafayette College Combustion Laboratory,CSS/CI-83-19,1983.
[7]	Rizk N K,Lefebvre A H.Prediction of velocity coefficient and spray cone angle for simplex swirl atomizers[C]//Proceedings of the 3rd International Conference on Liquid Atomization and Spray Systems.Volume 1,ICLASS-85,London,England:ICLASS,1986:ⅢC/2/1-ⅢC/2/16.
[8]	Rizk N K,Lefebvre A H.Influence of airblast atomizer design features on mean drop size[J].AIAA Journal,1983,21(8):1132-1142.
[9]	Lefebvre A H.Atomization and sprays[M].New York:Hemisphere pub.corp.,1989.
[10]	葛明龙.离心式喷嘴理论的改进[J].宇航学报,1981,2(4):85-97. GE Minglong.An improvement on the theory of swirl injector[J].Journal of Astronautics,1981,2(4):85-97.(in Chinese)
[11]	王之任.离心式喷嘴工况理论分析[J].推进技术,1996,17(5):1-8. WANG Zhiren.Theoretical analysis for operating condition of centrifugal injector[J].Journal of Propulsion and Power,1996,17(5):1-8.(in Chinese)
[12]	岳明,徐行,杨茂林.离心式喷嘴内气液两相流动的数值模拟[J].工程热物理学报,2003,24(5):888-890. YUE Ming,XU Xing,YANG Maolin.Numerical study of two-phase flow in atomizer[J].Journal of Engineering Thermophysics,2003,24(5):888-890.(in Chinese)
[13]	Ashraf A.Nonlinear breakup model for a liquid sheet emanating from a pressure-swirl atomizer[J].Journal of Engineering for Gas Turbines and Power,2007,129(10):945-953.
[14]	Datta A,So S K.Numerical prediction of air core diameter,coeffcient of discharge and spray cone angle of a swirl spray pressure nozzle[J].International Journal of Heat and Fluid Flow,2000,21(4):412-419.
[15]	Balasubramanyam M S,Chen C P.Numerical design studies on internal flow characteristics of LOX/CH₄ swirl injector[R].AIAA 2009-5040,2009.
[16]	Carlisle D R.Communication on the performance of a type of swirl atomizer[J].Proc. Inst. Mech. of Eng.,1995,209:169.
[17]	Elkotb M M,Rafat N M,Hanna M A.The influence of swirl atomizer geometry on the atomization performance[C]//Proceedings of the 1st International Conference on Liquid Atomization and Spray Systems.Tokyo Japan:ICLASS,1978:109-115.
