火焰筒浮动瓦块的壁温-结构一体化优化

高建辉; 温卫东; 崔海涛

火焰筒浮动瓦块的壁温-结构一体化优化

南京航空航天大学能源与动力学院, 南京 210016

计量
- 文章访问数: 1870
- HTML浏览量: 87
- PDF量: 441
- 被引次数: 0
出版历程
- 收稿日期: 2011-04-17
- 修回日期: 2011-10-27
- 刊出日期: 2012-03-28

Optimal design for temperature and structure of the float-wall of flame tube

College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 以火焰筒浮动瓦块结构为研究对象,提出了利用神经网络与遗传算法相结合的方法对浮动瓦块中冷却结构变量和安装位置变量进行同步优化.利用遗传算法分别对冷却结构变量和安装位置变量进行优化,将安装位置优化结果作为冷却结构变量优化中遗传操作的依据,最终实现冷却结构和安装位置的同步优化.为了通过计算效率,利用神经网络对安装位置的优化结果进行映射取代其优化过程.算例结果表明:该方法高效、精确,有很好的工程实用价值.
- 浮动瓦块 /
- 火焰筒 /
- 优化 /
- 神经网络 /
- 遗传算法
Abstract: Taking the float-wall structure as the object of study,neural network and genetic algorithm were used to settle synchronistically the optimization of cooling structures and install position.Using genetic algorithm to perform cooling structures and install position optimization,and taking the result of install position optimization as the foundation of cooling structures optimization,thus finally realized the synchronized optimizations of cooling structures and install position.In order to enhance the efficiency of algorithm,neural network was used to perform mapping on the result of install position optimization so as to replace its optimization processes.The result of calculating example shows that the method being mentioned is highly active,accurate and possesses good application value to engineering.
- float-wall /
- flame tube /
- optimization /
- neural network /
- genetic algorithm

HTML

参考文献(13)

[1]	梁春华.现代典型军民用涡扇发动机的先进技术[J].航空科学技术,2004,90(2):20-24. LIANG Chunhua.Modern typical military and civilian use advanced technology of turbofan engine[J].Aviation Science and Technology,2004,90(2):20-24.(in Chinese)
[2]	赵清杰,李彬.浮动瓦块冷却结构在燃烧室中的应用和发展[J].燃气涡轮试验与研究,2001,14(1):10-13. ZHAO Qingjie,LI Bin.Application and development of floating panel cooling structure in combustors[J].Gas Turbine Experiment and Research,2001,14(1):10-13.(in Chinese)
[3]	胡超,许全宏,徐剑,等.冲击/发散冷却壁温分布和冷却效率研究[J].航空动力学报,2008,23(10):1800-1804. HU Chao,XU Quanhong,XU Jian,et al.Investigation of the wall temperature distribution and cooling efficiency for impingement/effusion cooling scheme[J].Journal of Aerospace Power,2008,23(10):1800-1804.(in Chinese)
[4]	Cho H H,Rhee D H,Goldstein R J.Effect of hole arrangements on local heat/mass transfer for impingement/effusion cooling with small hole spacing.ASME GT2004-53685,2004.
[5]	陈焱,吉洪湖,胡娅萍,等.致密微孔壁绝热冷却效果研究[J].工程热物理学报,2006,27(增2):25-28. CHEN Yan,JI Honghu,HU Yaping,et al.Investigation of adiabatic cooling effectiveness of an effusion cooled plate[J].Journal of Engineering Thermophysics,2006,27(Suppl 2):25-28.(in Chinese)
[6]	林宇震,俞文利,刘高恩,等.冲击加发散双层壁冷却方式压降分配对斜孔内对流换热影响的研究[J].航空学报,2003,24(2):97-101. LIN Yuzhen,YU Wenli,LIU Gaoen,et al.Influence of pressure drop distribution on the convection heat transfer inside the inclined hole of impingement/effusion cooling[J].Acta Aeronautica et Astronautica Sinica,2003,24(2):97-101.(in Chinese)
[7]	宋双文,杨卫华,胡好生,等.冲击+逆向对流+气膜冷却传热特性的研究[J].航空动力学报,2007,22(9):1418-1421. SONG Shuangwen,YANG Weihua,HU Haosheng,et al.Experimental study of the heat transfer characteristics of combined cooling of impingement+reversed[J].Journal of Aerospace Power,2007,22(9):1418-1421.(in Chinese)
[8]	李彬,吉洪湖,江义军.冲击-发散冷却火焰筒浮动瓦片三维壁温计算分析[J].航空动力学报,2007,22(3):370-374. LI Bin,JI Honghu,JIANG Yiju.Numerical analysis of 3D temperature field of an impingement-effusion cooled flame tube floating tile[J].Journal of Aerospace Power,2007,22(3):370-374.(in Chinese)
[9]	李彬.冲击-致密微孔浮动壁火焰筒冷却研究.南京:南京航空航天大学,2007. LI Bin.Investigation of impingement/effusion float-wall cooling of flame tube.Nanjing:Nanjing University of Aeronautics and Astronautics,2007.(in Chinese)
[10]	张宏建.燃烧室浮动壁结构优化方法研究.南京:南京航空航天大学,2005. ZHANG Hongjian.Structure optimization method of the float-tile.Nanjing:Nanjing University of Aeronautics and Astronautics,2005.(in Chinese)
[11]	王伟,杨伟,赵美英,等.基于神经网络与杂交算法的机翼结构优化设计[J].机械设计,2007,24(8):49-52 WANG Wei,YANG Wei,ZHAO Meiying,et al.Optimization design of aerofoil structure based on neural network and hybridization algorithm[J].Journal of Machine Design,2007,24(8):49-52.(in Chinese)
[12]	王维刚,龙飞.基于BP神经网络和改进遗传算法的蒸发器支座结构优化设计[J].化工机械,2009,36(4):317-322. WANG Weigang,LONG Fei.Optimum design of support brackets of evaporators based on BP neural network and improved genetic algorithm[J].Chemical Engineering and Machinery,2009,36(4):317-322.(in Chinese)
[13]	邓江华,刘献栋,冯国胜.基于神经网络和遗传算法的车身骨架结构优化设计[J].农业机械学报,2007,38(6):26-29. DENG Jianghua,LIU Xiandong,FENG Guosheng.Optimal design of bus frame structure on the basis of ANN and GE[J].Transactions of the Chinese Society of Agricultural Machinery,2007,38(6):26-29.(in Chinese)
