超临界压力下碳氢燃料在竖直圆管内换热特性

张斌; 张春本; 邓宏武; 徐国强; 朱锟

超临界压力下碳氢燃料在竖直圆管内换热特性

北京航空航天大学能源与动力工程学院航空发动机气动热力国家级重点实验室, 北京 100191

基金项目: 国家自然科学基金(50676005)

计量
- 文章访问数: 1813
- HTML浏览量: 132
- PDF量: 480
- 被引次数: 0
出版历程
- 收稿日期: 2011-04-07
- 修回日期: 2011-09-22
- 刊出日期: 2012-03-28

Heat transfer characteristics of hydrocarbon fuel at supercritical pressure in vertical circular tubes

National Key Laboratory of Science and Technology on Aero-Engine Aero-thermcolynamics, School of Jet Propulsion, Beijing University of Aeronautics Astronautics, Beijing 100191, China

摘要

摘要: 以国产航空煤油RP-3为对象研究了超临界压力下热流密度和进口温度对碳氢燃料在竖直向上管和竖直向下管的换热特性的影响.实验中热流密度变化范围为300~600kW/m²,进口温度变化范围为293~723K,压力及流量分别保持为5MPa以及3g/s.研究表明:在所有实验工况下,实验进口处将首先出现换热恶化现象,之后随着热边界层的充分发展换热逐渐增强;当管内流体状态从超临界压力液态过渡到超临界状态,由于物性的显著变化将导致换热沿管程方向得到显著强化.当进口油温超过其拟临界温度后,由于碳氢燃料吸热能力迅速降低导致管内出现了换热恶化.对于竖直向上流与竖直向下流,即使浮升力判断因子的值小于10^-5,浮升力的影响仍然不能忽略.最后,在实验结果基础上,提出了超临界压力碳氢燃料在微细管内流动的强迫对流换热经验关系式.
- 超临界压力 /
- 拟临界温度 /
- 碳氢燃料 /
- 浮升力 /
- 传热系数
Abstract: Experimental results of convection heat transfer to supercritical hydrocarbon fuel (RP-3) in heated vertical tubes were reported in this paper.The effects of heat flux,inlet temperature and flow direction (upward and downward) on heat transfer were studied.In the experiments,the pressure and mass flow rate were maintained at 5MPa and 3g/s the respectively;the heat flux changed from 300kW/m² to 600kW/m² and the inlet temperature ranged from 293K to 673K.Test results indicate that heat transfer deterioration appears firstly at the inlet of the heated test section and then increases after thermal boundary layer is developed totally.In addition,heat transfer is enhanced near the critical point of the fuel due to the significant changes of thermalphysics properties;when the inlet temperature of RP-3 exceeds its pseudo-critical temperature,heat transfer deterioration occurs again due to the heat capacity of RP-3 decreases rapidly,Furthermore,the heat transfer coefficient of RP-3 in downward flow is greater than that in upward flow due to the buoyancy effect even if the value of determining factor is lower than 10^-5.Based on the experimental data,correlations are developed for the local Nusselt number of convection heat transfer to supercritical hydrocarbon fuel in vertical miniature heated tubes.
- supercritical pressure /
- pseudo-critical temperature /
- hydrocarbon fuel /
- buoyancy /
- heat transfer coefficient

HTML

参考文献(15)

[1]	梁春华.IHPTET计划的最新进展[J].国际航空,2004(2):58-60. LIANG Chuanhua.Advance of IHPTET[J].Interntional Aiation,2004(2):58-60.( in Chinese)
[2]	Brad H,Michael K.Enhancement of heat transfer and elimination of flow oscillations in supercritical fuels.Cleveland,OH:34th AIAA/ASME/SAE/ASEE Joint Propulsion Conference and Exhibit,1998.
[3]	Brad H,Michael K.Experimental investigation of heat transfer and flow instabilities in supercritical fuels.Seattle,WA:33rd AIAA/ASME/SAE/ASEE Joint Propulsion Conference and Exhibit,1997.
[4]	Hines W S,Wolf H.Pressure oscillations associated with heat transfer to hydrocarbon fluid at supercritical pressures and temperatures[J].American Rocket Society Journal,1962,32(3):361-366.
[5]	Linne D L,Meyer M L,Braun D C.Investigation of instabilities and heat transfer phenomena insupercritical fuels at high heat flux and temperatures.Huntsville,AL:36th AIAA/ASME/SAE/ASEE Joint Propulsion Conference and Exhibit,2000.
[6]	胡志宏,陈听宽,罗毓珊,等.超临界压力下煤油传热特性试验研究[J].西安交通大学学报,1999,33(9):33-37. HU Zhihong,CHEN Tingkuan,LUO Yushan,et al.Heat transfer characteristics of kerosene at supercritical pressure[J].Journal of Xi’an Jiaotong University,1999,33(9):33-37.( in Chinese)
[7]	张春本,邓宏武,徐国强,等.超临界压力下航空煤油RP-3焓值的测量及换热研究[J].航空动力学报,2010,25(2):331-335. ZHANG Chunben,DENG Hongwu,XU Guoqiang,et al.Enthalpy measurement and heat transfer investigation of RP-3 kerosene at supercritical pressure[J].Journal of Aerospace Power,2010,25(2):331-335.( in Chinese)
[8]	DENG Hongwu,ZHANG Cunben,XU Guogiang,et al.Density measurements of endothermic hydrocarbon fuel at sub-and supercritical conditions[J].Journal of Chemical and Engineering Data,2011,56(6):2980-2986.
[9]	ZHANG Cunben,TAO Zhi,XU Guoqiang,et al.Heat transfer invest igation of the sub-and supercritical fuel flow through a U-turn tube.Antalya,Turkey:Turbine-09,the ICHMT Int.Symposium on Heat Transfer in Gas Turbine Systems,2009.
[10]	孙青梅,米镇涛,张香文.吸热型碳氢燃料RP-3仿JP-7临界性质的测定[J].燃料化学学报,2006,34(4):466-470. SUN Qingmei,MI Zhentao,ZHANG Xiangwen.Determination of critical properties of endothermic hydrocarbon fuels RP-3 and simulated JP-7[J].Journal of Fuel Chemistry and Technology,2006,34(4):466-470.(in Chinese)
[11]	Jackson J D,Cotton M A,Axcell B P.Studies of mixed convection in vertical tubes[J].International Journal of Heat Fluid Flow,1989,10(1):2-15.
[12]	周强泰.超临界压力水的管内强迫对流传热[J].华中科技大学学报(自然科学版),1983,11(1):89-93. ZHOU Qiangtai.Forced convection heat transfer to supercritical pressure water in tubes[J].Journal of Huazhon University of Science Technology (Natural Science Edition),1983,11(1):89-93.( in Chinese)
[13]	Linne D L,Meyer M L,Edwards T,et al.Evaluation of heat transferand thermal stability of supercritical JP-7 fuel.AIAA 1997-3041,1997.
[14]	Liao S M,Zhao T S.An experimental investigation of convection heat transfer to supercriticalcarbon dioxide in miniature tubes[J].International Journal of Heat and Mass Transfer,2002,45(25):5025-5034.
[15]	Jackson J D,Hall W B.Influence of buoyancy on heat transfer to fluids flowing in vertical tubes under turbulent conditions.Hemisphere,New York,USA:Turbulent Forced Convection in Channels and Bundles(Vol.2),1979:613-640.
