小型短寿命涡扇发动机涡轮叶片疲劳失效分析

洪杰; 刘书国; 张大义; 陈萌

小型短寿命涡扇发动机涡轮叶片疲劳失效分析

北京航空航天大学能源与动力工程学院, 北京 100191

计量
- 文章访问数: 1707
- HTML浏览量: 100
- PDF量: 443
- 被引次数: 0
出版历程
- 收稿日期: 2011-04-27
- 修回日期: 2011-07-12
- 刊出日期: 2012-03-28

Fatigue failure analysis of turbine blade in miniature short-life turbofan engine

School of Jet Propulsion, Beijing University of Aeronautics and Astronautics, Beijing 100191, China

摘要

摘要: 针对某小型短寿命涡扇发动机台架试车中涡轮叶片断裂故障,进行了叶片断口分析、振动监测信号对比和结构动力学特性分析.讨论了叶片的固有振动特性与激振因素,阐明了该叶片故障主要是由叶片机匣严重碰摩激起的叶片以第一阶、第二阶及其耦合模态自由振动,导致的叶片根部高周疲劳破坏.提出合理控制转静子初始间隙和提高叶片根部阻尼,能有效防止该类型故障发生.
- 叶片 /
- 疲劳 /
- 振动 /
- 碰摩 /
- 断裂
Abstract: For the fracture fault of the high-pressure turbine blade in the miniature short-life turbofan engine during a certain rig test,the blade fractography,the vibration signal and the fault blade dynamics was observed and analyzed.Blades natural characteristics and exciting sources were analyzed in details;the faults mainly stemmed from fatigue for the 1st order,the 2nd order and the coupled mode vibrations due to the instantaneous severe rub impact force.Reasonable control of the clearance and improving the blade root damping can prevent the fault effectively.
- blade /
- fatigue /
- vibration /
- rub impact /
- fracture
