热斑对涡轮级转静干涉噪声影响数值研究

母忠强; 乔渭阳; 赵磊

热斑对涡轮级转静干涉噪声影响数值研究

西北工业大学动力与能源学院, 西安 710072

计量
- 文章访问数: 1526
- HTML浏览量: 0
- PDF量: 428
- 被引次数: 0
出版历程
- 收稿日期: 2011-04-24
- 修回日期: 2011-07-11
- 刊出日期: 2012-03-28

Investigation of tonal noise in high pressure turbine stage due to non-uniform inlet entropy of inflow

School of Power and Energy, Northwestern Polytechnical University, Xi’an 710072, China

摘要

摘要: 利用结合相位延迟方法的求解器,对进口有热斑存在的某高压涡轮级流场进行三维非定常计算,然后利用模态匹配方法在涡轮转子下游管道中提取出转静干涉离散噪声信息.通过与进口无热斑存在算例比较表明:在一倍叶片通过频率下,向下游传播的转静干涉离散噪声总声功率级增加了约5.9dB;在二倍叶片通过频率下增加了约11.6dB.
- 涡轮级转静干涉噪声 /
- 叶片通过频率 /
- 相位延迟方法 /
- 模态匹配方法 /
- 声功率级
Abstract: Through using the flow solver which activated phase-lag method,got the three-dimensional(3-D) unsteady flow field in a high pressure turbine stage which had hot spots in inlet,and then by using the mode matching method in the duct of downstream rotor,the rotor-stator interaction discrete noise which propagated downstream was obtained.After compared with the case without hot spots in turbine inlet,the results show that the total acoustic power level of rotor-stator interaction discrete noise emitted in the downstream direction is increased by 5.9dB at the blade-passing frequency and by remarkably 11.6dB at the first harmonic of the blade-passing frequency.
- turbine stage rotor-stator interaction noise /
- blade passing frequency /
- phase-lag method /
- mode matching method /
- acoustic power level

HTML

参考文献(17)

[1]	Cumpsty N A,Marble N E.Core noise from gas-turbine exhausts[J].Journal of Sound and Vibration,1977,54(2):297-309.
[2]	Cumpsty N A,Marble N E.The interaction of entropy fluctuations with turbine blade rows;a mechanism of turbojet engine noise[J].Proc. Roy. Soc. London A,1977,357(1690):323-344.
[3]	Marble F E,Candel S M.Acoustic disturbance from gas non-uniformities convected through a nozzle[J].Journal of Sound and Vibration,1977,55(2):225-243.
[4]	Cumpsty N A.Jet engine combustion noise-Pressure,entropy and vorticity produced by unsteady combustion or heat addition[J].Journal of Sound and Vibration,1979,66(4):527-544.
[5]	Leykoa M,Nicoudc F,Poinsote T.Numerical and analytical investigation of the indirect combustion noise in a nozzle,combustion for aerospace propulsion[J].Comptes Rendus Mecanique,2009,337(6):415-425.
[6]	Bake F,Michel U,Rohle I.Investigation of entropy noise in aero-engine combustors[J].J. Eng. Gas Turbines Power,2007,129(2):370-376.
[7]	Bake F,Kings N,Roehle I.Fundamental mechanism of entropy noise in aero-engines:experimental investigation[J].J.Eng.Gas Turbines Power,2008,130(1):1-6.
[8]	Bake F,Richter C.The entropy wave generator (EWG):a reference case on entropy noise[J].Journal of Sound and Vibration,2009,326(3-5):574-598.
[9]	He L.Method for simulating unsteady turbomachinery flows with multiple pertubations[J].AIAA Journal,1992,30(11):2730-2735.
[10]	Ovenden N C,Rienstra S W.Mode-matching strategies in slowly varying engine ducts[J].AIAA Journal,2004,42(9):1832-1840.
[11]	Tapken U,Raitor T,Enghardt L.Tonal noise reduction from an UHBR fan-optimized induct radial mode analysis.AIAA-2009-3288,2009.
[12]	Weckmüeller C,Guerin S,Ashcroft G.CFD-CAA coupling applied to DLR UHBR-fan:comparison to experimental data.AIAA -2009-3342,2009.
[13]	Steger M,Michel U,Ashcroft G,et al.Turbofan tone noise reduction by flow-induced unsteady blade forces[M]//King R.Active flow control Ⅱ:notes on numerical fluid mechanics and multidisciplinary design.Berlin:Springer,2010,108:157-170.
[14]	Giles M B.Non-reflecting boundary conditions for euler equation calculations[J].AIAA Journal,1990,28(12):2050-2058.
[15]	Schnell R.Numerische simulation des akustischen nahfeldes einer triebwerksgebl asestufe.Berlin:Herrman Fottinger Institut for Fluid Mechanics,2004.
[16]	Tyler J M,Sofrin T G.Axial flow compressor noise studies[J].Transactions of the Society of Automotive Engineers,1962,70:309-332.
[17]	Holste F,Neise W.Acoustic near field measurement on a propfan model for noise source identification.AIAA-95-178,1995.
