三维造型对高负荷跨声风扇静子的影响分析

徐朋飞; 刘宝杰; 赵斌

三维造型对高负荷跨声风扇静子的影响分析

北京航空航天大学能源与动力工程学院航空发动机气动热力国防科技重点实验室, 北京 100191

计量
- 文章访问数: 1573
- HTML浏览量: 156
- PDF量: 447
- 被引次数: 0
出版历程
- 收稿日期: 2011-04-18
- 修回日期: 2011-07-04
- 刊出日期: 2012-03-28

Analysis of three-dimensional blading influence on highly loaded transonic fan stator

National Key Laboratory of Science and Technology on Aero-Engines, School of Jet Propulsion, Beijing University of Aeronautics and Astronautics, Beijing 100191, China

摘要

摘要: 以负荷系数高达0.42的跨声风扇进口级为背景,利用三维数值模拟手段,研究了叶片三维气动造型技术对高负荷跨声风扇静子气动性能的影响,并深入地分析了其影响机理.结果表明:由于激波在静子叶根有垂直于轮毂端壁的趋势,因此前掠造型对于激波/端壁附面层所主导的静子角区分离的控制效果并不明显;相比之下,正弯静子通过加入叶片力使得角区中的低速流体向叶中发生径向迁移,显著地改善了静子的性能;而复合弯掠进一步提高了静子的性能,说明单纯使用前掠造型收效不佳,需要配合正弯造型才能达到最佳效果.
- 掠形 /
- 弯形 /
- 静子 /
- 跨声风扇 /
- 高负荷
Abstract: Under the background of highly loaded transonic inlet fan stage,which produces loading coefficient of 0.42,three-dimensional(3-D) blading influence on transonic stator aerodynamic performance was analyzed as well as its mechanism with numerical simulation technology.The result indicates that the forward sweep is not effective to control the corner separation conducted by shock/endwall boundary layer interaction because of the trend that the shock always tends to remain perpendicular to the endwall.Positive bow modifies the stator performance obviously through adding the blade force to migrate the low-speed corner fluid toward to mid-span.Sweep/bow composition improves the stator performance further,illustrating that the benefit from pure forward sweep is limited and forward sweep can attain optimum effect when combining the positive bow.
- sweep /
- bow /
- stator /
- transonic fan /
- highly loaded

HTML

参考文献(12)

[1]	Law C H,Wadia A R.Low aspect ratio transonic rotors:part1-baseline design and performance[J].ASME Journal of Turbomachinery,1993,115(2):218-225.
[2]	Wennerstrom A J.Highly loaded axial flow compressor:history and current developments[J].ASME Journal of Turbomachinery,1990,112(4):567-578.
[3]	陈葆实,胡国荣,魏玉冰,等.高马赫数、高负荷单级风扇设计和试验研究[J].航空发动机,2000(3):28-35. CHEN Baoshi,HU Guorong,WEI Yubing,et al.Design and test research of highly loaded,highly Mach single-stage fan[J].Aero-Engine,2000(3):28-35.(in Chinese)
[4]	Merchant A A,Kerrebrock J L,Adamczyk J J,et al.Experimental investigation of a high pressure ratio aspirated fan stage[J].ASME Journal of Turbomachinery,2005,127(1):43-51.
[5]	Tweedt D L,Okiishi T H,Hathaway M D.Stator endwall leading-edge sweep and hub shroud influence on compressor performance.ASME Paper 86-GT-197,1986.
[6]	Sasski T,Breugelmans F.Comparison of sweep and dihedral effects on compressor cascade performance[J].ASME Journal of Turbomachinery,1998,120(3):454-463.
[7]	Gallimore S J,John J B,Nicholas A C,et al.The use of sweep and dihedral in multistage axial flow compressor blading Part Ⅰ:university research and method development.ASME Paper GT-2002-30328,2002.
[8]	Gummer V,Wenger U,Kau H P.Using sweep and dihedral to control three-dimensional flow in transonic stators of axial flow compressors[J].ASME Journal of Turbomachinery,2006,128(1):357-366.
[9]	Friedrichs J,Baumgart S,Kosyna G,et al.Effect of stator design on stator boundary layer flow in highly loaded single-stage axial-flow low-speed compressor[J].ASME Journal of Turbomachinery,2001,123(3):483-489.
[10]	冯秀莲,金东海,桂幸民.叶片弯掠对压气机静子叶片气动性能影响的三维数值模拟[J].航空动力学报,2009,24(10):2338-2343. FENG Xiulian,JIN Donghai,GUI Xingmin.Numerical simulation of the aerodynamics performance of swept and curved blade on the compressor stator[J].Journal of Aerospace Power,2009,24(10):2338-2343.(in Chinese)
[11]	Song Y P,Chen F,Yang J,et al.A numerical investigation of boundary layer suction in compound lean compressor cascade[J].ASME Journal of Turbomachinery,2001,123:40-48.
[12]	Denton J D,Xu L.The effect of lean and sweep on transonic fan performance.ASME Paper GT-2002-30327,2002.
