环形腔室径向宽度对加力燃油泵内流及性能影响

薛梅新; 吴迪; 朴英

环形腔室径向宽度对加力燃油泵内流及性能影响

清华大学航天航空学院, 北京 100084

基金项目: 中国博士后科学基金(20100480259)

计量
- 文章访问数: 1830
- HTML浏览量: 61
- PDF量: 469
- 被引次数: 0
出版历程
- 收稿日期: 2011-04-19
- 修回日期: 2011-06-30
- 刊出日期: 2012-03-28

Effect of annular chamber radial width on the performance and inner flow characteristics of an after-burning oil pump

School of Aerospace, Tsinghua University, Beijing 100084, China

摘要

摘要: 对某加力燃油泵内部非定常流动开展了系统的数值模拟,研究了不同环形腔室径向宽度条件下泵的外特性和内流特征.计算结果表明,缩小径向宽度可有效提高泵在不同流量下的扬程,且小流量工况增幅显著高于大流量,明显改善了小流量工作的不稳定性.对于大流量工况,环形腔室截面变小导致腔室内循环流量降低、沿程损失明显减小,是泵出口扬程提高的主要因素;而对于小流量工况,环形腔室截面变小使得扩散管主流贴近环形腔室,显著降低了叶轮流道扬程损失,有效提升了泵出口扬程.
- 部分流泵 /
- 加力燃油泵 /
- 航空发动机 /
- 环形腔室 /
- 数值模拟
Abstract: A series of unsteady numerical simulations was conducted for an after-burning oil pump and the effect of annular chamber radial width on the pump performance and inner flow characteristics was investigated.Decrease of the radial width can increase the pump head under different flow-rates and the head increase under small flow-rate condition is larger than that under large flow-rate condition,which improves operation stability under the small flow-rate.Under the large flow-rate condition,annular chamber head loss is reduced by the decrease of circulation flow-rate in annular chamber resulted from the decrease of the annular chamber and following circumferential section area.Accordingly pump head is raised.While,under the small flow-rate condition,decreasing annular chamber radial width makes the incoming flow of the diffuser approach to annular chamber,which reduces the impeller passage head loss.As a result,pump head is enhanced significantly.
- partial emission pump /
- after-burning oil pump /
- aero-engine /
- annular chamber /
- numerical simulation

HTML

参考文献(12)

[1]	Barske U M.Development of some unconventional centrifugal pumps[J].Proceedings of the Institution of Mechanical Engineers,1960,174(1):437-461.
[2]	吴玉珍.部分流式切线泵在高效率条件下扬程系数的确定[J].化工设备与管道.2000,37(3):37-39. WU Yuzhen.Determination of head coefficient for part flow tangent pumps with high efficiency[J].Process Equipment & Piping,2000,37(3):37-39.(in Chinese)
[3]	朱祖超.开式高速离心泵的试验研究[J].浙江大学学报(工学版),1999,33(2):34-38. ZHU Zuchao.Experimental study on high-speed centrifugal pumps with an open impeller[J].Journal of Zhejiang University (Engineering Science),1999,33(2):34-38.(in Chinese)
[4]	朱祖超,麻明祥.小流量高扬程高速离心泵的加大流量设计[J].浙江大学学报(工学版),2001,35(1):11-15. ZHU Zuchao,MA Mingxiang.Increasing-flow design on small-flow-rate high-head high-speed centrifugal pumps[J].Journal of Zhejiang University (Engineering Science),2001,35(1):11-15.(in Chinese)
[5]	王乐勤,朱祖超.超低比转速高速诱导轮离心泵的不稳定控制与试验研究[J].工程热物理学报,1998,19(3):315-319. WANG Leqin,ZHU Zuchao.Instability-control and experimental study of superlow specific speed high-speed inducer-centrifugal pumps[J].Journal of Engineering Thermophysics,1998,19(3):315-319.(in Chinese)
[6]	陈党民,李新宏,黄淑娟.部分流泵整机非定常流动数值模拟[J].工程热物理学报,2005,26(S1):89-92. CHEN Dangmin,LI Xinhong,HUANG Shujuan.Numerical analysis of the unsteady flow field for a partial emission pump[J].Journal of Engineering Thermophysics,2005,26(S1):89-92.(in Chinese)
[7]	崔宝玲,赵瑞,张玉良,等.高速开式离心泵内部的流动特性研究[J].工程热物理学报,2010,31(4):601-605. CUI Baoling,ZHAO Rui,ZHANG Yuliang,et al.The research on flow characteristics of high-speed centrifugal pump with open impeller[J].Journal of Engineering Thermophysics,2010,31(4):601-605.(in Chinese)
[8]	张剑慈,崔宝玲,李昳,等.低比转速开式叶轮高速离心泵的优化设计系统[J].机械工程学报,2006,42(7):19-23. ZHANG Jianci,CUI Baoling,LI Yi,et al.Optimum design system of low-specific open-impeller high-speed centrifugal pump[J].Chinese Journal of Mechanical Engineering,2006,42(7):19-23.(in Chinese)
[9]	刘在伦,曾宪湘.蜗壳形状对高速部分流泵性能的影响[J].流体机械,2009(3):40-44. LIU Zailun,ZENG Xianxiang.Study on the performance of high-speed partial emission pump caused by the shape of volute[J].Fluid Machinery,2009,37(3):40-44.(in Chinese)
[10]	柴立平,潘兵辉,石海峡,等.高速部分流泵CFD计算和优化设计[J].排灌机械工程学报,2010,28(3):211-214. CHAI Liping,PAN Binghui,SHI Haixia,et al.CFD calculation and optimal design of high-speed partial emission pump[J].Journal of Drainage and Irrigation Machinery Engineering,2010,28(3):211-214.(in Chinese)
[11]	徐朝晖,吴玉林,陈乃祥,等.基于滑移网格与RNG湍流模型计算泵内的动静干扰[J].工程热物理学报,2005,26(1):66-68. XU Zhaohui,WU Yulin,CHEN Naixiang,et al.Simulation of turbulent flow in pump based on sliding mesh and RNG k-ε model[J].Journal of Engineering Thermophysics,2005,26(1):66-68.(in Chinese)
[12]	Barth T J,Jespersen D C.The design and application of upwind schemes on unstructured meshes.AIAA-1989-366,1989.
