机载中空纤维膜富氮性能实验

刘小芳; 刘卫华; 钱国诚; 赵宏韬

机载中空纤维膜富氮性能实验

1.
南京航空航天大学航空宇航学院, 南京 210016
2.
安徽工业大学冶金与资源学院, 安徽马鞍山 243002
3.
江淮航空供氧制冷设备有限公司技术中心, 合肥 230035

基金项目: “十一五”工业和信息化部民机预研项目(GA89267); 国家自然科学基金 (50906066); 安徽省高等学校优秀青年人才基金(2009SQRZ79)

计量
- 文章访问数: 1734
- HTML浏览量: 77
- PDF量: 574
- 被引次数: 0
出版历程
- 收稿日期: 2011-06-22
- 刊出日期: 2012-05-28

Experimentation on nitrogen-enriched characteristics of on-board hollow fibre membrane

1.
College of Aerospace Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China
2.
College of Metallurgy & Resources, Anhui University of Technology, Ma’anshan Anhui 243002, China
3.
Technology Center, Jianghuai Aviation Oxygen Supply and Refrigeration Equipment Corporation Limited Company, Hefei 230035, China

摘要

摘要: 通过建立机载中空纤维膜环境模拟性能实验平台,对与国内某技术中心合作研制的机载中空纤维膜进行了系统的环境模拟性能实验及分析.实验结果显示:①渗余富氮空气氧体积分数随输入空气压力的上升而下降,随输入流量的上升而上升,而与输入空气温度基本无关;②渗余富氮空气氧体积分数随富氮空气流量的上升而上升,且输入空气压力低时明显;③海拔高度对机载中空纤维膜富氮性能基本不影响,仅启动时渗余富氮空气氧体积分数略有下降.通过采用多元回归方法,得到有一定普遍意义的机载膜富氮性能公式.
- 机载中空纤维膜 /
- 富氮性能 /
- 飞机燃油系统惰化 /
- 氧体积分数 /
- 回收率
Abstract: The experimentation and analysis of on-board hollow fibre membrane,which were jointly designed by a technic center,were systemically implemented by ground condition simulation.Results show that:(1) the oxygen concentration descends with input pressure increasing,ascends with input flux arising,and then is basically independent of the temperature of input air;(2) the oxygen concentration increases with the output flux gained,especially under the low pressure of input air;(3) the effect of height above sea level on the nitrogen-enriched performance of the membrane is light.The formula of nitrogen-enriched performance was found by multielement regression and validated by the comparison of experimental results.
- on-board hollow fibre membrane /
- nitrogen-enriched characteristics /
- aircraft fuel tank inerting /
- oxygen fraction /
- reclaiming ratio

HTML

参考文献(15)

[1]	肖再华.飞机燃油箱惰化[J].航空科学技术,2005(1):31-33. XIAO Zaihua.Inerting aircraft fuel tanks[J].Aviattion Technology,2005(1):31-33.(in Chinese)
[2]	田宏,吴穹,江平,等.网状聚氨酯泡沫材料的发展[J].航空材料学报,2001,21(2):59-63. TIAN Hong,WU Qiong,JIANG Ping,et al.The development of reticulated polyurethane foam[J].Journal of Aeronutical Materials,2001,21(2):59-63.(in Chinese)
[3]	张辉,刘应书,李永玲,等.机载制氮系统在油箱防火中的应用和研究进展[J].低温与特气,2007,27(4):1-5. ZHANG Hui,LIU Yingshu,LI Yonglin,et al.Applications and development tedencies of on board oxygen generating systems in aviation field[J].Low Temperature and Specialty Gases,2009,27(4):1-5.(in Chinese)
[4]	Knight T C,Ritter J E.Nitrogen inerting of aircraft fuel tanks.AIAA-1984-2480,1984.
[5]	Desmarais L A,Yagle W J,Grenich A F.On-board inert gas generator system(OBIGGS) studies Part 3:aicraft OBIGGS designs.AFWAL-TR-85-2060,1984.
[6]	Cavage W M.The cost of implementing ground-based fuel tank inerting in the commercial fleet.DOT/FAA/AR-00/19,2000.
[7]	胡传东.机载惰性气体产生系统[J].直升机技术,2002,130(2):47-50. HU Chuandong.On-board inert gas generation system[J].Helicopter Technology,2002,130(2):47-50.(in Chinese)
[8]	杨琳.如何防止飞机燃油油箱爆炸[J].新技术应用,2003,36(12):56-57. YANG Lin.New technology to prevent fuel tank explosion[J].Application of New Technology,2003,36(12):56-57.(in Chinese)
[9]	Burns M,Cavage W M,Hill R,et al.Flight -testing of the FAA onboard inert gas generation system on an airbus A320.DOT/FAA/AR-03/58,2004.
[10]	Cavage W M,Bownan T.Modeling in-flight inert gas distribution in a 747 center wing fuel tank.AIAA-2005-4906,2005.
[11]	Baer M R,Gross R J.A combustion model for the TWA 800 center-wing fuel tank explosion.SAND 98-2043,1998.
[12]	Cavage W M,Summer S.A study of the flammability of commercial transport airplane wing fuel tanks.DOT/FAA/AR-08/8,2008.
[13]	Summer S.Cold ambient temperature effects on heated fuel tank vapor concentrations.DOT/FAA/AR-TN99/93,2000.
[14]	陈勇,王从厚,吴鸣.气体膜分离技术与应用[M].北京:化学工业出版社,2004:118-119.
[15]	王磊.膜分离过程的优化与控制方法研究.大连:大连理工大学,2006. WANG Lei.Study on optimization and control methods for membrane separation process.Dalian:Dalian University of Science and Engineer,2006.(in Chinese)
