水滴撞击特性参数的动态图像测量方法

刘丹阳; 韩雅慧; 丁立; 杨春信

水滴撞击特性参数的动态图像测量方法

北京航空航天大学航空科学与工程学院, 北京 100191

计量
- 文章访问数: 1597
- HTML浏览量: 1
- PDF量: 567
- 被引次数: 0
出版历程
- 收稿日期: 2011-06-10
- 刊出日期: 2012-05-28

Dynamic image processing measurement method of droplets impingement characteristics

School of Aeronautics Science and Engineering, Beijing University of Aeronautics and Astronautics, Beijing 100191, China

摘要

摘要: 以染色法为基本原理,实验采集试件表面不同位置的染色过程视频.通过对视频数据的分析获取试件表面色度随时间增长的时序信号.实验过程可以划分为欠饱和区、平衡区和过饱和区.平衡区的比色值分布即为局部水收集系数分布的归一化结果.通过比色积分曲线的极限行为确定水滴撞击极限和总收集系数与最大局部水收集系数的比值.将实验结果与数值仿真结果和NASA(美国国家航空航天局)实验结果对比表明:水滴撞击特性参数与动态视频图像的RGB(rad-green-blue)色度空间可以建立较好的关联,实验重复性误差率小于±15%;水滴撞击特性参数之间存在内在关联.
- 防冰 /
- 水滴撞击特性 /
- 图像处理 /
- 动态测量 /
- 圆柱
Abstract: Image processing method was applied to analyze the dying process at different locations on test cylinders in order to examine the variation of the surface chroma during the test.A complete test was divided into three stages:sub-dyed,balanced and over-dyed.The chroma distribution of balanced stage was normalized and defined as local water collection efficiency.Droplet impingement limits and the ratio of total impingement to the maximum local impingement efficiency can therefore be analyzed by the colorimetric integration curves.Comparing to the numerical simulation and the experiment of NASA (National Aeronautics and Space Administration),the current results indicate that water droplets impingement characteristics can be correlated with the dynamic RGB(rad-green-blue) color space,with ±15% repeatability error.Interrelation among the three characteristics was also observed.
- anti-icing /
- water droplet impingement characteristics /
- image processing /
- dynamic measurement /
- cylinder

HTML

参考文献(12)

[1]	Sabri F,Trifu O,Parachivoiu R I.In-flight ice accretion simulation in SLD conditions.AIAA-2007-4282,2007.
[2]	NTSB.Ntsb team investigation airliner crash near buffalo..http://www.ntsb.gov/pressrel/ 2009/090213.html.
[3]	NTSB.Most wanted transportation safety improvements aviation issue areas..http://www.ntsb.gov/recs/ mostwanted/aviation_issues.htm.
[4]	Gelde T F,Smyers W H,Von Glahn U.Experimental droplet impingement on several two-dimensional airfoils with thickness ratios of 6 to 16 percent.NACA TN 3839,1956.
[5]	Lewis J P,Ruggeri R S.Experimental droplet impingement on four bodies of revolution.NACA TN 4092.1957.
[6]	Gelder T F.Droplet impingement and ingestion by supersonic nose inlet in subsonic tunnel conditions.NACA TN 4268,1958.
[7]	Papadakis M,Elangonan R,Freund G A,et al.An experimental method for measuring water droplet impingement efficiency on two- and three-dimensional bodies.NASA CR 4257,1989.
[8]	Papadakis M,Kuohsing E Hung,Giao T V.Experimental investigation of water droplet impingement on airfoils,finite wings,and an S-duct engine inlet.NASA/TM—2002-211700,2002.10.
[9]	Papadakis M,Rachman A,Wong S C.Water impingement experiments on a NACA 23012 airfoil with simulated glaze ice shapes.AIAA-2004-0565,2004.
[10]	Papadakis M,Hung K E,Rachman A,et al.Experimental study of supercooled large drop impingement on ice shapes.DOT/FAA/AR-08/13.
[11]	Bourgault Y,Habashi W G,Dompierre J,et al.An Eulerian approach to supercooled droplets impingment calculations.AIAA-1997-0176,1997.
[12]	Bourgault Y,Boutanios Z,Habashi W G.Three-dimensional Eulerian approach to droplet impingement simulation using FENSAP-ICE Part 1:model,algorithm and validation[J].Journal of Aircraft,2000,37(1):95-103.
