基于层流小火焰和beta-PDF的预混燃烧模型

杨金虎; 刘富强; 徐纲; 朱俊强

基于层流小火焰和beta-PDF的预混燃烧模型

1.
中国科学院工程热物理研究所, 北京 100190
2.
中国科学院研究生院, 北京 100190

基金项目: 国际科技合作项目(2010DFB70620); 国家重点基础研究发展计划(2007CB210109)

计量
- 文章访问数: 2412
- HTML浏览量: 127
- PDF量: 684
- 被引次数: 0
出版历程
- 收稿日期: 2011-06-13
- 刊出日期: 2012-05-28

Premixed combustion model based on laminar flamelet and presumed beta-PDF

1.
Institute of Engineering Thermophysics, Chinese Academy of Sciences, Beijing 100190, China
2.
Graduate University of Chinese Academy of Sciences, Beijing 100190, China

摘要

摘要: 研究了基于层流小火焰概念和假定beta-PDF(probability density function)的湍流预混燃烧模型.该模型采用PREMIX程序来计算层流小火焰,将计算结果表示为进程变量的函数,并利用进程变量的beta-PDF积分生成了用于RANS(雷诺平均Navier-Stokes)计算的PDF表.以化学当量的甲烷湍流本生火焰为算例对模型进行了计算验证,并与Zimont模型的计算结果和实验结果做了对比.结果表明,平均速度分布与实验符合的较好,温度和湍动能计算结果有待改善.本模型高估了化学反应速率,导致计算火焰比实际瘦,这是因为模型中未能考虑湍流对火焰的拉伸和弯曲效应,考虑湍流拉伸和弯曲效应的预混燃烧模型是今后进一步研究的方向.
- 预混燃烧 /
- 进程变量 /
- 层流小火焰 /
- beta-PDF(probability density function) /
- 本生火焰
Abstract: Based on the laminar flamelet concept and the presumed beta-PDF(probability density function),a turbulent premixed combustion model was studied.In this model,the laminar flamelet calculation was performed with one dimensional free propagation flame code,PREMIX.The results of the laminar flamelet calculation can be formulated as functions of progress variable and then integrated with the presumed beta-PDF,which produced a lookup table.This model was validated with the calculation of the turbulent Bunsen flame for stoichiometric methane.The results were compared with the results of Zimont model and the experiment,which show that the calculation here can appropriately predict the distribution of average velocity.However,the turbulent kinetic energy and temperature are not so well captured and the mean reaction rate is likely overpredicted,which lead to a shorter flame brush.This is likely because of the exclusion of turbulent stretch effect on the flame surface.A model which can account for the effect of turbulent stretch will be explored in future studies.
- premixed combustion /
- progress variable /
- laminar flamelet /
- beta-PDF(probability density function) /
- Bunsen flame

HTML

参考文献(12)

[1]	姚强,李水清,王宇.燃烧学导论[M].北京:清华大学出版社,2009.
[2]	Bray K N C.The challenge of turbulent combustion //Proceedings of the 26th Sympositumn Combustion.Naples,Italy:The Combustion Istitute,1996:1-26.
[3]	Bilger R W.Future progress in turbulent combustion research[J].Progress in Energy and Combustion Science,2000,26(4-6):367-380.
[4]	侯凌云,杨成仁,傅维标.小火焰模型在贫燃预混火焰中的研究[J].工程热物理学报,2003,24(5):873-876. HOU Lingyun,YANG Chengren,FU Weibiao.The application of flamelet model in lean premixed flame[J].Journal of Engineering Thermophysics,2003,24(5):873-876.(in Chinese)
[5]	王方,周力行,许春晓,等.预混燃烧大涡模拟和燃烧模型的校验[J].推进技术,2008,29(1):33-36. WANG Fang,ZHOU Lixing,XU Chunxiao,et al.Large eddy simulation of premixed combustion and the validation of the combustion model[J].Journal of Propulsion Technology,2008,29(1):33-36.(in Chinese)
[6]	Kolla H.Scalar dissipation rate based flamelet modeling of turbulent premixed flames.Cambridge,UK:Department of Engineering,Cambridge University,2009.
[7]	Poinsot T,Veynante D.Theoretical and numerical combustion[M].Philadephia,USA:Edwards,2001.
[8]	Kolla H,Swaminathan N.Strained flamelets for turbulent premixed flames Ⅰ :formulation and planar flame results[J].Combustion and Flame,2010,157(5):943-954.
[9]	Kee R J,Grcar J F,Smooke M D,et al.A fortran program for modeling a steady laminar one-dimensional premixed flame.Report No.SAND85-8240,1985.
[10]	Kolla H,Rogerson J W,Chakraborty N,et al.Scalar dissipation rate modeling and its validation[J].Combustion Science and Technology,2009,181(3):518-535.
[11]	Chen Y C,Peters N,Schneemann G A,et al.The detailed flame structure of highly stretched turbulent premixed methane-air flames[J].Combustion and Flame,1996,107(3):223-244.
[12]	Herrmann M.Numerical simulation of turbulent Bunsen flames with a level set flamelet model[J].Combustion and Flame,2006,145(1-2):357-375.
