组合压气机旋转失速特征的小波分析

单晓明; 姚峥嵘; 岳林; 黄金泉

组合压气机旋转失速特征的小波分析

1.
南京航空航天大学能源与动力学院, 南京 210016
2.
中国航空工业集团公司中国航空动力机械研究所, 湖南株洲 412002
3.
南京航空航天大学机电学院, 南京 210016

计量
- 文章访问数: 1840
- HTML浏览量: 192
- PDF量: 645
- 被引次数: 0
出版历程
- 收稿日期: 2011-07-02
- 刊出日期: 2012-05-28

Wavelet analysis of features of rotating stall in a combined compressor

1.
College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China
2.
China Aviation Powerplant Research Institute, Aviation Industry Corporation of China, Zhuzhou Hunan 412002, China
3.
College of Mechanical and Electrical Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 采用高频响动态压力探针测量了小流量轴流/离心组合压气机的旋转失速和喘振,并采用基于Morlet小波时频分析和小波系数奇异分解的方法分析了压气机失速信号.研究结果表明:稳定工况下,频率分量较多、幅值较小.失速工况下,特征频率能量较大、且成倍频关系.在该组合压气机的失稳过程中,并没有引起大幅度的压力脉动.压气机光滑地从失速前出现的模态波过渡到完全失速.周向存在2个失速团,失速团传播速度约为44.8%~45.9%转速.
- 高频响探针 /
- 失速 /
- 压气机 /
- 小波分析 /
- 奇异值分解
Abstract: A fast response pressure probe was applied to test the rotating stall and surge of an axial and centrifugal combined compressor.The pressure signals were analyzed by utilizing the method of the time-frequency analysis based on the Morlet and singular value decomposition.The experimental results indicate that,at the stable condition,there are many main frequency components in the frequency domain but the amplitude is small,while,at the stall condition,the energy of the frequency components becomes larger.In the process of unstall to stall,the larger amplitude of the pressure fluctuation does not produced by the stall cell in this compressor.The compressor enters smoothly into the full stall condition from the modal wave.2 stall cells are measured around annulus and the propagation speed of the stall cell is from 44.8% to 45.9% rotor speed.
- fast response probe /
- stall /
- compressor /
- wavelet analysis /
- singular value decomposition(SVD)

HTML

参考文献(16)

[1]	Emmons H W,Pearson C F,Grant H P.Compressor surge and stall propagation[J].Transactions of the ASME,1955,77(2):455-469.
[2]	Moore F K,Greitzer E M.A theory of post-stall transients in axial compression systems Part 1:development of equations[J].ASME Journal of Engineering for Gas Turbines and Power,1986,108(1):68-76.
[3]	Epstein A H,Williams J E,Greitzer E M.Active suppression of aerodynamic instabilities in turbomachines[J].Journal of Propulsion and Power,1989,5(2):204-211.
[4]	McDougall N M,Cumpsty N A,Hynes T P.Stall inception in axial compressors[J].ASME Journal of Turbomachinery,1990,112(1):116-125.
[5]	Day I J.Stall inception in axial flow compressors[J].ASME Journal of Turbomachinery,1993,115(1):1-9.
[6]	Longley J P.Inlet distortion and compressor instabilities.Cambridge:Cambridge University,1988.
[7]	Bright M M,Qammar H K,Weigl H J,et al.Stall precursor identification in high speed compressor stages using chaotic time series analysis methods[J].ASME Journal of Turbomachinery,1997,119(3):491-499.
[8]	Tryfonidis M,Etchvers O,Paduano J D,et al.Pre-stall behavior of several high-speed compressors[J].Journal of Turbomachinery,1995,117(1):62-80.
[9]	Cameron J,Morris S.Spatial correlation based stall inception analysis[J].ASME Conference Proceedings,2007,2007(47950):433-444.
[10]	Torrence C,Compo G.A practical guide to wavelet analysis[J].Bulletin of the American Meteorological Society,1998,79(1):61-78.
[11]	LIN Feng,CHEN Jingyi,LI Meilin.Wavelet analysis of rotor-tip disturbances in an axial-flow compressor[J].Journal of Propulsion and Power,2004,20(2):319-334.
[12]	LIN Feng,CHEN Jingyi,LI Meilin.Practical issues of wavelet analysis of unsteady rotor tip flows in compressors //Indianapolis,Indiana:38th AIAA/ASME/SAE/ASEE Joint Propulsion Conference & Exhibit,2002:2002-4082.
[13]	Salunkhe P B,Pradeep A M,Stall inception mechanism in an axial flow fan under clean and distorted inflows[J].Journal of Fluids Engineering,2010,132(12):121102-1121115.
[14]	张靖煊.一种捕捉预示压气机失稳预警信号的新方法的研究[J].航空动力学报,2004,19(2):270-277. ZHANG Jingxuan.Study of a new method for giving warning signals of instability[J].Journal of Aerospace Power,2004,19(2):270-277.(in Chinese)
[15]	聂超群.低速轴流压气机旋转失速先兆[J].工程热物理学报,1998,19(3):293-298. NIE Chaoqun.Experimental investigation on inception of rotating stall in low-speed axial compressor[J].Journal of Engineering Thermophysics,1998,19(3):293-298.(in Chinese)
[16]	程晓斌.小波分析与压气机旋转失速先兆研究.北京:中国科学院工程热物理研究所,2000. CHENG Xiaobin.Investigation on the method of wavelet transform and the inception process of compressor rotating stall.Beijing:Institute of Engineering Thermophysics,Chinese Academy of Sciences,2000.(in Chinese)
