基于NURBS曲线的轴流透平叶片气动 数值优化

王录; 刘海清; 张宏武; 杨建道

基于NURBS曲线的轴流透平叶片气动数值优化

1.
中国航天科技集团公司北京空间飞行器总体设计部, 北京 100094
2.
中国科学院工程热物理研究所, 北京 100190
3.
中国科学院研究生院, 北京 100190
4.
上海电气电站设备有限公司汽轮机厂, 上海 200240

计量
- 文章访问数: 1640
- HTML浏览量: 115
- PDF量: 544
- 被引次数: 0
出版历程
- 收稿日期: 2011-06-07
- 刊出日期: 2012-05-28

Numerical aerodynamic optimization of axial turbomachinery blades based on NURBS

1.
Institute of Spacecraft System Engeneering, China Aerospace Science and Technology Corporation, Beijing 100094, China
2.
Institute of Engineering Thermophysics, Chinese Academy of Science, Beijing 100190, China
3.
Graduate University of Chinese Academy of Science, Beijing 100190, China
4.
Turbing Plant, Shanghai Electric Power Generation Equipment Company Limited, Shanghai 200240, China

摘要

摘要: 通过搭建适用于轴流式透平叶片气动数值优化的设计平台,对某NASA透平级动静叶片进行等熵效率、流量相对变化、落压比相对变化的多目标寻优.该平台包括三个核心模块: 叶片的参数化造型、流场气动性能评估、优化策略.采用非均匀有理B样条(NURBS)曲线对叶片进行参数化拟合;针对叶片气动数值优化的多变量、多模态的特征,采用试验设计和遗传算法组合优化策略进行寻优.经过气动优化, 在设计工况点优化叶片性能较原始叶片有明显提高,为轴流式叶片的气动优化提供了可借鉴的措施.
- NURBS曲线 /
- 遗传算法 /
- 多目标优化 /
- 轴流透平叶片 /
- 气动优化
Abstract: A NASA(National Aeronautics and Space Administration) transonic single stage turbine was taken as an example,describing how to use an aerodynamic numerical optimization platform to find the optimal solution.The platform had three parts:parameterization and fitting of blades,simulation of flow field and optimization strategy.Blades were parameterized based on non-uniform rational B-splines(NURBS) curve.Integrated optimizationstrategy which included DOE(design of experiments) method and genetic algorithm was used to find the global optimal solution.Results show that the performance is improved at the optimized work point.The platform provides a useful reference for analogous optimization of axial turbomachinery blades.
- non-uniform rational B-splines (NURBS) /
- genetic algorithm /
- multi-objective optimization /
- axial turbomachinery blades /
- aerodynamic optimization

HTML

参考文献(13)

[1]	Burguburu S,Toussaint C,Bonhomme C.Numerical optimization of ourbomachinery oladings[J].ASME,Journal of Turbomachinery,2004,126(1):91-100.
[2]	CHEN Naixing,ZHANG Hongwu,HUANG Weiguang,et al.Study on aerodynamic design optimiza- tion of turbomachinery blades[J].Journal of Thermal Science,2005,14(4):298-304.
[3]	Lotifi O,Lvey P C.Aerodynamic optimization of industrial fan blade cascades.ASME Paper GT2005-68385,2005.
[4]	ÖKSVZ Ö,Akmandor S.Turbine blade shape aerodyn- amic design using artificial intelligence.ASME Paper GT2005-68094,2005.
[5]	Briasco G,Bruna D,Cravero C.A NURBS-based optimization tool for axial compressor cascades at design and off-design.ASME Paper GT2008-50622,2008.
[6]	薛亮,韩万金.基于遗传算法与近似模型的全局气动优化方法[J].推进技术,2008,29(3):21-26. XUE Liang,HAN Wanjin.Global aerodyneamic optimization method using genetic algorithems and surrogate model[J].Journal of Propulsion Technology,2008,29(3):21-26.(in Chinese)
[7]	Mengistu T,Ghaly W,Mansour T.Aerodynamic shape optimization of turbine blades using a design-parameter-based shape representation.ASME Paper GT2007-28041,2007.
[8]	ZHOU Fanzhen,FENG Guotai,JIANG Hongde.The development of highly loaded turbine rotating blades by using 3D optimization design method of turbomachinery blades based on artificial neural network & genetic algorithm[J].Chinese Journal of Aeromautics,2003,16(4):198-202.
[9]	Obayashi S,Sasaki D,Oyama A.Finding trad-eoffs by using multi-objective optimization algorithms[J].Transactions of JSASS,2004,47(155):51-58.
[10]	LI Jun,LI Guojun,FENG Zhenping.Multi-objective optimization approach to turbomachinery blades design.ASME Paper GT2005-68303,2005.
[11]	Burguburu S,Toussaint C,Bonhomme C,et al.Numerical optimization of turbomachinery bladings[J].Journal of Turbomachinery,2004,126(1):91-100.
[12]	Moffit T P.Design and cold air test of single stage uncooled core turbine with high work output.NASA TP-1680,1980.
[13]	王录.轴流式叶轮机械叶片气动数值优化设计研究.北京:中国科学院,2010. WANG Lu.The study of areodynamic numerical optimization design of axial of turbomacnihery blades.Beijing:Chinese Academy Sciences,2010.(in Chinese)
