叶片全三维反问题优化设计方法

朱阳历; 王正明; 陈海生; 谭春青

叶片全三维反问题优化设计方法

1.
中国科学院工程热物理研究所, 北京 100190
2.
中国科学院研究生院, 北京 100049

基金项目: 国家自然科学基金(50906079); 国家重点基础研究发展计划(2012CB720400)

计量
- 文章访问数: 1747
- HTML浏览量: 100
- PDF量: 588
- 被引次数: 0
出版历程
- 收稿日期: 2011-06-21
- 刊出日期: 2012-05-28

Full 3-D inverse design optimization method for turbomachinery blade

1.
Institute of Engineering Thermophysics, Chinese Academy of Sciences, Beijing 100190, China
2.
Graduate University of Chinese Academy of Sciences, Beijing 100049, China

摘要

摘要: 基于数值求解Navier-Stokes方程,对叶轮机械叶片全三维反问题优化设计方法进行研究.反问题给定叶片表面的静压分布反求叶型,假设叶表网格点有虚拟移动速度,迭代过程中根据叶表的实际静压和目标静压之差来修改叶型.对单排叶栅进行了反问题设计,并给出了初步的优化算例,结果能很好地满足目标静压分布,验证了该方法的有效性,计算的时间和精度也适合进行工程应用.
- 全三维反问题设计 /
- 叶片优化 /
- 叶轮机械 /
- Navier-Stokes方程 /
- 激波
Abstract: Full 3-D inverse design optimization method for turbomachinary blade was studied,which was based on numerical solver of Navier-Stokes equations.Pressure distribution on blade surface was specified for obtaining the corresponding blade profile in inverse problem,assuming there was virtual velocity of grid node on blade surface;blade geometry was modified by the difference between surface pressure and target pressure during iterative procedure.Inverse designs of cascade and optimization example indicate that solution of new blade profile matches target pressure well,which validates effectiveness of this method.The method is practical for engineering applications in time cost and accuracy.
- full 3-D inverse design /
- blade optimization /
- turbomachine /
- Navier-Stokes equation /
- shock

HTML

参考文献(16)

[1]	Beatty T D,Narramore J C.Inverse method for the design of multielement high-lift systems[J].Journal of Aircraft,1976,13(6):393-398.
[2]	WANG Zhengming.Inverse design calculations for transonic cascades[J].International Journal of Turbo and Jet Engines,1987,4(3/4):217-224.
[3]	Thompkins W T,Tong S S.Inverse or design calculations for nonpotential flow in turbomachinery blade passages[J].Journal of Turbomachinery,1982,104(2):281-285.
[4]	Dang T,Damle S,Qiu X.Euler-based inverse method for turbomachine blades Part 2:three-dimensional cascades[J].AIAA Journal,2000,38(11):2007-2013.
[5]	Demeulenaere A,Van den Braembussche R.Three-dimensional inverse method for turbomachinery blading design[J].Journal of Turbomachinery,1998,120(2):247-255.
[6]	WANG Zhengming,CAI Ruixian,CHEN Hongji,et al.A three-dimensional inverse method using Navier-Stokes equation for turbomachinery blading[J].Inverse Problems in Engineering,2000,8(6):529-551.
[7]	Mileshin V I,Orekhov I K.3D inverse design of transonic fan rotors efficient for a wide range of RPM.ASME Paper GT2007-27817,2007.
[8]	Watanabe H,Zangeheh M.Design of the blade geometry of swept transonic fans by 3D inverse design.ASME Paper GT-2003-38770,2003.
[9]	Roidl B,Ghaly W.Redesign of a low speed turbine stage using a new viscous inverse design method[J].Journal of Turbomachinery,2011,133(1):011009(9 pages).
[10]	Borges J E.A three-dimensional inverse method for turbomachinery part Ⅰ:theory[J].Journal of Turbomachinery,1990,112(3):346-354.
[11]	罗兴琦,陈乃祥,林汝长.混流式转轮内有旋流动的全三元反问题计算[J].力学学报,1995,27(增刊):30-36. LUO Xingqi,CHEN Naixiang,LIN Ruchang.Inverse calculation of a full three dimensional rotational flow for mixed flow runner[J].Acta Mechanica Sinica,1995,27(Supplement):30-36.(in Chinese)
[12]	王正明,蔡睿贤,陈宏冀,等.叶栅全三维粘性反问题的数值解[J].工程热物理学报,1998,19(5):571-575. WANG Zhengming,CAI Ruixian,CHEN Hongji,et al.Numerical solution of fully 3D viscous inverse problem of turbomachinery blading[J].Journal of Engineering Thermophysics,1998,19(5):571-575.(in Chinese)
[13]	陈乃兴,徐燕骥,黄伟光,等.单转子风扇的三维反问题气动设计[J].航空动力学报,2002,17(1):23-28. CHEN Naixing,XU Yanji,HUANG Weiguang,et al.An inverse method for 3-D aerodynamic design of fans and pumps[J].Journal of Aerospace Power,2002,17(1):23-28.(in Chinese)
[14]	李颖晨,丰镇平.透平叶栅三维粘性气动反问题的控制理论方法[J].工程热物理学报,2007,28(4):580-582. LI Yingchen,FENG Zhenping.Control theory method for aerodynamic inverse problem of 3D viscous turbine blades[J].Journal of Engineering Thermophysics,2007,28(4):580-582.(in Chinese)
[15]	姚吉先,刘前智,周新海.压气机叶片排内三维紊流流动的隐式高分辨率数值分析[J].航空动力学报,1996,11(3):225-228. YAO Jixian,LIU Qianzhi,ZHOU Xinhai.Numerical analysis of three-dimensional turbulent flow in compressor blade row by implicit high-resolution scheme[J].Journal of Aerospace Power,1996,11(3):225-228.(in Chinese)
[16]	Strazisar A J,Wood Jerry R,Hathaway M D,et al.Laser anemometer measurements in a transonic axial-flow fan rotor.NASA TP-2879,1989.
