基于精确参数化定义的复合材料桨叶剖面 扭转刚度计算

杨建灵; 张丽艳; 周少华; 方永红; 黄文俊

基于精确参数化定义的复合材料桨叶剖面扭转刚度计算

1.
南京航空航天大学机电学院, 南京 210016
2.
中国航空工业集团公司中国直升机设计研究所, 江西景德镇 333001

计量
- 文章访问数: 1952
- HTML浏览量: 122
- PDF量: 544
- 被引次数: 0
出版历程
- 收稿日期: 2011-06-21
- 刊出日期: 2012-05-28

Cross-section torsion stiffness calculation of composite rotor blade based on accurate parametric definition

1.
College of Mechanical and Electrical Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China
2.
Chinese Helicopter Research and Development Institute, Aviation Industry Corporation of China, Jingdezhen Jiangxi 333001, China

摘要

摘要: 在系统地对桨叶结构设计流程、结构分析计算方法进行研究的基础上,通过对桨叶组件参数化定义及桨叶铺层三维几何建模方法的扩展,自动获得各桨叶剖面相关组件的几何和材料信息,并基于闭口薄壁梁理论,给出了复合材料桨叶剖面扭转刚度的高效计算方法.该方法一方面充分考虑了复合材料蒙皮铺层的复杂结构以及梁、肋等组件的细节几何模型,避免了三维几何模型简化误差;另一方面,提出了铺层块、等效厚度以及长厚比概念,并采用解析表达,将模型几何解构完全集成于桨叶设计过程自动完成,十分便于工程应用.实例验证表明:提出的方法能够快速、可靠地完成桨叶剖面扭转刚度计算,显著提高设计分析效率.
- 复合材料 /
- 旋翼 /
- 桨叶 /
- 参数化设计 /
- 结构分析
Abstract: A new method was proposed to improve the calculation of the composite rotor’s torsion stiffness.First,the flow of the blade’s structure design and analysis were studied.Then,all the material and geometry profile information of the blade construction were obtained by expanding the methods of blade parametric module definition and blade geometric modeling.Finally,the efficient calculation equations for cross-section torsion stiffness of composite rotor blade were derived based on the thin-box beam theory.One of the advantages of the proposed method lies in that the precision loss of model simplification is eliminate by taking the blade’s refined geometric model.On the other side,by importing the ply block,equivalent thickness and slenderness radio conception,and due to the analytical form of the calculation and the automatic geometric extraction,this method is quite suitable for practical use.Experimental results demonstrate that the method can complete the blade structure design and analysis efficiently.
- composite material /
- rotor /
- blade /
- parametric design /
- structure analysis

HTML

参考文献(20)

[1]	路录祥.直升机结构与设计[M].北京:航空工业出版社,2009.
[2]	Fung Y C.An introduction to the theory of aeroelasticity[M].New York:Dover Publi Inc.,1993.
[3]	Bauchau O A.A beam theory for anisotropic materials[J].Journal of Applied Mechanics,1985,52(2):416-422.
[4]	Giavotto V,Borri M,Mantegazza P,et al.Anisotropic beam theory and applications[J].Computer Structures,1983,16(1-4):403-413.
[5]	Hodges D H,Atilgan A R,Cesnik C E S,et al.On a simplified strain energy function for geometrically nonlinear behavior of anisotropic beams[J].Composites Engineering,1992,2(5-7):513-526.
[6]	Johnson E R,Vasiliev V V,Vasiliev D V.Anistotropic thin-walled beams with closed cross-sectional contours[J].AIAA Journal,2001,39(12):2389-2393.
[7]	Vlasov V Z.Thin-walled elastic beams[M].Washington D C:National Science Foundation,1961.
[8]	Mansfield E H,Sobey A J.The fiber composite helicopter blade,Part 1:stiffness properties Part 2:prospects for aeroelastic tailoring[J].Aeronautical Quarterly,1979,30(2):413-449.
[9]	Mansfield E H.The stiffness of a two-cell anisotropic tube[J].Aeronautical Quarterly,1981,32(4):338-353.
[10]	Chandra R,Chopra I.Experimental and theoretical analysis of composite I-beams with elastic couplings[J].AIAA Journal,1991,29(12):2197-2206.
[11]	Chandra R,Stemple A D,Chopra I.Thin-walled composite beams under bending,torsional and extensional loads[J].Journal of Aircraft,1990,27(7):619-626.
[12]	Worndle R.Calculation of the cross section properties and the shear stresses of composite rotor blades[J].Vertica,1982,6(2):111-129.
[13]	Bauchau O A,Hong C H.Finite element approach to rotor blade modeling[J].Journal of the American Helicopter Society,1987,32(1):60-67.
[14]	Kosmatka J B.Structural dynamic modeling of advanced composite propellers by the finite element method.Los Angeles:University of California,1986.
[15]	向锦武,张晓谷,赵翔.直升机旋翼桨叶截面刚度的有限元计算[J].航空动力学报,1998,13(2):206-208. XIANG Jinwu,ZHANG Xiaogu,ZHAO Xiang.A calculation of cross-sectional stiffness of composite helcopter blade[J].Journal of Aerospace Power,1998,13(2):206-224.(in Chinese)
[16]	Chakravarty U K.Section builder:an innovative finite element tool for analysis and design of composite rotor blade cross-sections[J].Composite Structures,2010,92(2):284-294.
[17]	Oden J T.Mechanics of elastic structures[M].New York:McGraw-Hill Inc.,1967:47-55.
[18]	杨建灵,张丽艳,方永红,等.基于参数化描述的复合材料桨叶结构设计[J].南京航空航天大学学报,2009,41(5):595-600. YANG Jianling,ZHANG Liyan,FANG Yonghong,et al.Structure design for composite rotor blade based on parametric module definition[J].Journal of Nanjing University of Aeronautics and Astronautics,2009,41(5):595-600.(in Chinese)
[19]	杨建灵,张丽艳,周少华,等.直升机复合材料桨叶铺层三维几何建模方法[J].航空学报,2010,31(1):199-205. YANG Jianling,ZHANG Liyan,ZHOU Shaohua,et al.Geometric modeling of composite helicopter rotor blade plies[J].Acta Aeronautic et Astronautica Sinica,2010,31(1):199-205.(in Chinese)
[20]	YANG Jianling,ZHANG Liyan.Rotor SIM:a coupled multidisciplinary simulation integration framework for helicopter rotor blade design //Proceeding of 2009 WRI World Congress on Software Engineering.Xiamen:WCSE,2009:456-460.
