基于多体动力学的旋翼模型与气弹稳定性

虞志浩; 杨卫东; 邓景辉; 张呈林

基于多体动力学的旋翼模型与气弹稳定性

1.
南京航空航天大学航空宇航学院直升机旋翼动力学重点实验室, 南京 210016
2.
中国直升机设计研究所直升机旋翼动力学重点实验室, 江西景德镇 333001

基金项目: 国家重点基础研究发展计划

计量
- 文章访问数: 1899
- HTML浏览量: 123
- PDF量: 569
- 被引次数: 0
出版历程
- 收稿日期: 2011-09-16
- 刊出日期: 2012-05-28

Model of rotor aeroelastic stability using dynamics of flexible multbody systems

1.
Science and Technology on Rotorcraft Aeromechanics Laboratory, College of Aerospace Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China
2.
Science and Technology on Rotorcraft Aeromechanics Laboratory, China Helicopter Research and Development Institute, Jingdezhen Jiangxi 333001, China

摘要

摘要: 针对无轴承等先进旋翼结构特点,建立了基于柔性多体系统动力学方法的旋翼气弹分析模型.旋翼各构件建模相互独立,便于组成不同构型旋翼,适合于新构型旋翼气弹分析.分析模型集成了适合于旋翼气弹分析的隐式大变形桨叶模型,构件动力学方程增加了铰链动力学方程,统一约束方程形式,改进了角运动约束方程,避免连续旋转引起的奇点问题.应用分析模型计算无铰式旋翼和无轴承旋翼的气弹稳定性,分析结构参数对旋翼气弹稳定性的影响.分析结果表明模型能准确计算结构弹性变形的耦合及非线性,提高旋翼气弹稳定性分析精度.
- 旋翼 /
- 多体系统动力学 /
- 气动弹性 /
- 稳定性 /
- 无轴承旋翼
Abstract: Aeroelastic model of rotor was developed using dynamics of flexible multibody systems.The modeling of components of rotor was independent,so different rotor configurations can be modeled and the model was appropriate for new configuration rotor aeroelastic analysis.A large deflection beam model,suitable for aeroelastic analysis of rotor,was incorporated.To simplify the form of constraint equations,dynamic equations of component including a joint were deduced.To avoid singularities for large rotations,the angular constraint equations,expressed by Rodriguez parameters,were modified by introduced a nominal motion.To verify the correctness of the developed method,the aeroelastic analysis of helicopter rotor and influence study of blade structure parameters were implemented.It demonstrates that the method is very useful for improving computation precision of aeroelastic stability.
- rotor /
- dynamics of multibody systems /
- aeroelasticity /
- stability /
- bearingless rotor

HTML

参考文献(16)

[1]	Lim I G,Lee I.Aeroelastic analysis of bearingless rotors using large deflection beam theory[J].AIAA Journal,2007,45(3):599-606
[2]	Hopkins A S,Scientist R,Ormiston R A,et al.An examination of selected problems in rotor blade structural mechanics and dynamics[J].Journal of the American Helicopter Society,2006,51(1):104-125.
[3]	Bir G,Chopra I.University of marrland advanced rotorcraft code(UMARC) theory manual.UM Aero Report,92-02,1992.
[4]	Chopra I.Dynamic stability of bearingless circulation control rotor blade in hover[J].Journal of the American Helicopter Society,1985,30(4):40-47.
[5]	Saberi H,Khoshlahjeh M,Ormiston R A.Overview of RCAS and application to advanced rotorcraft problems //Proceedings of AHS 4th Decennial Specialist’s Conference on Aeromechanics.Washington DC:AHS International,2004:452-471.
[6]	Johnson W.Rotorcraft dynamics models for a comprehensive analysis //Proceedings of AHS 54th Annual Forum.Washington DC:AHS International,1998:452-471.
[7]	韩东,高正,王浩文,等.直升机桨叶刚柔耦合特性及计算方法分析[J].航空动力学报,2006,21(1):36-40. HAN Dong,GAO Zheng,WANG Haowen,et al.Analysis of the computational method and the helicopter blade characteristics with coupled rigid and elastic motions[J].Journal of Aerospace Power,2006,21(1):36-40.(in Chinese)
[8]	邓景辉.直升机先进旋翼气弹稳定性研究.南京:南京航空航天大学,2009. DENG Jinghui.Helicopter advanced rotor aeroelasticity stability research.Nanjing:Nangjing University of Aeronautics and Astronautics,2009.(in Chinese)
[9]	虞志浩,董凌华,邓景辉,等.旋翼异形桨叶大变形气弹动力学分析与试验研究[J].南京航空航天大学学报,2011,43(3):312-317. YU Zhihao,DONG Linhua,DENG Jinghui,et al.Analysis and experimental study on aeroelasticity of rotor with special-shaped blade using large deflection theory[J].Journal of Nangjing University of Aeronautics & Astronautics,2011,43(3):312-317.(in Chinese)
[10]	Shabana A A.Dynamics of multibody systems[M].Cambridge:Cambridge University Press,2005:59-62.
[11]	Leishman J G.Principle of helicopter aerodynamics[M].Cambridge:Cambridge University Press,2006.
[12]	陆佑方.柔性多体系统动力学[M].北京:高等教育出版社,1996:274-299.
[13]	Hodges D H.Nonlinear composite beam theory[M].Virginia:AIAA,2006:262-269.
[14]	Maier T H.Aeroelastic stability for straight and swept-tip rotor blades in hover and forward flight //Proceedings of AHS 55th Annual Forum.Washington DC:AHS International,1999:1031-1047.
[15]	Maier T H,Sharpe D L.Fundamental investigation of hingless rotor aeroelastic stability //Proceedings of AHS 51th Annual Forum.Washington DC:AHS International,1995:1176-1190.
[16]	Maier T H,Abrego A I.Analytical model sensitivity study for aeroelastic stability of straight and swept-tip rotor blades //Proceeding of European Rotorcraft Forum,26th.Netherlands:The Hague,2000:70(15 pages).
