基于弹体表面吹气的埋入式进气道性能改善

程代姝; 孙姝; 温玉芬; 谭慧俊

基于弹体表面吹气的埋入式进气道性能改善

1.
南京航空航天大学能源与动力学院, 南京 210016
2.
南京航空航天大学民航学院, 南京 210016

基金项目: 国家自然基金(10802036); 南航青年科技创新基金(NS2010176)

计量
- 文章访问数: 1899
- HTML浏览量: 82
- PDF量: 654
- 被引次数: 0
出版历程
- 收稿日期: 2011-06-08
- 刊出日期: 2012-05-28

Submerged inlet performance improvement with blowing on fuselage

1.
College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China
2.
College of Civil Aviation, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 针对埋入式进气道进口处吸入了大量的弹身边界层低能流而导致的总压恢复系数较低,出口流场畸变较大的问题,提出了一种基于弹体表面吹气的埋入式进气道流场控制概念,并采用数值仿真先对不带进气道的纯弹身模型进行了边界层控制研究,而后进一步对完整的进气道/弹身模型进行了仿真分析,获得了吹气控制措施对埋入式进气道流动结构和工作性能的影响特性.结果表明:合适的吹气方案确实能够有效地吹除部分弹身边界层,改善埋入式进气道进口前的边界层状况及内通道流态,提高其总压恢复系数并降低出口流场畸变.设计状态下埋入式进气道的总压恢复系数提高了1.5%,畸变指数降低了6.6%.
- 埋入式进气道 /
- 边界层 /
- 吹气 /
- 总压恢复系数 /
- 畸变指数
Abstract: Due to the large amount of boundary layer ingested into the submerged inlet which results in low total pressure recovery and high flow distortion,a flow control method based on blowing on the fuselage was introduced.By computational method,the models without and with inlet were both studied to obtain the effects of blow technique on the performance and flow structure of submerged inlet.Results indicate that the control method is effective to blow fuselage boundary layer,and improve the boundary layer condition before entrance and the flow in the duct.At the design condition,the total pressure recovery coefficient increased by 1.5% and the distortion index decreased by 6.6% as compared with the baseline case.
- submerged inlet /
- boundary layer /
- blow /
- total pressure recovery coefficient /
- distortion coefficient

HTML

参考文献(14)

[1]	李学来.埋入式进气道的技术现状[J].福州大学学报:自然科学版,2001,29(6):61-66. LI Xuelai.Development of submerged intake[J].Journal of Fuzhou University (Natual Science Edition),2001,29(6):61-66.(in Chinese)
[2]	Mossman E A,Randall L M.An experimental investigation of the design variables for NACA.NACA RM-A7I30,1948.
[3]	Hall C F,Frank J L.Ram-recovery characteristics of NACA submerged inlets at high subsonic speeds.NACA RM-A8I29,1948.
[4]	Axelson J A,Taylor R A.Preliminary investigation of the transonic characteristics of an NACA submerged inlet.NACA RM-A50C13,1950.
[5]	Frank J L.Pressure-distribution and Ram-recovery characteristics of NACA submerged inlets at high subsonic speeds.NACA RM-A50E02,1950.
[6]	Anderson W E,Frazer A C.Investigation of an NACA submerged inlet at Mach numbers from 1.17 to 1.99.NACA RM-A52F17,1952.
[7]	任三星.埋入式进气道设计与流场控制研究.南京:南京航空航天大学,1993 REN Sanxing.Design and flow control investigation of a submerged air intake.Nanjing:Nanjing University of Aeronautics and Astronautics,1993.(in Chinese)
[8]	Taskinoglu E S,Knight D.Design optimization for submerged inlets PartⅠ.AIAA 2003-1247,2003.
[9]	Taskinoglu E S,Knight D.Design optimization for submerged inlets Part Ⅱ.AIAA 2003-3926,2003.
[10]	Taskinoglu E S,Jovanovic V,Knight D.Multi-objective design optimization and experimental measurement for a submerged inlet.AIAA 2004-0025,2004.
[11]	Jovanovic V,Taskinoglu E S,Knight D.Experimental investigation of a submerged subsonic innlet.AIAA 2004-2649,2004.
[12]	Taskinoglu E S,Knight D.Multi-objective shape optimization study for a subsonic submerged inlet[J].Journal of Propulsion and Power,2004,20(4):620-633.
[13]	余安远,郭荣伟,孙姝,等.一种隐身外形弹体下埋入式进气道的进气机理与低速实验研究[J].空气动力学报,2003,21(2):182-188. YU Anyuan, GUO Rongwei, SUN Shu, et al. Air- admission mechanism and low speed tunnel test fo a submerged inlet with low RCS missile body[J].Acta Aerodynamic Snica,2003,21(2):182-188.(in Chinese)
[14]	Sun S,Guo R W.Numerical analysis and experimental validation of a submerged inlet on the plane surface [J].Chinese Journal of Aeronautics,2005,18(3):199-205.
