轴连轴承温度场的有限元分析

王燕霜; 祝海峰; 刘喆

轴连轴承温度场的有限元分析

1.
河南科技大学机电工程学院, 河南洛阳 471003
2.
陕西汽车集团汉德车桥有限公司, 西安 710201

基金项目: 国家科技支承计划(JPPT-115-189); 河南省高校创新人才项目(2011HASTIT016)

计量
- 文章访问数: 1875
- HTML浏览量: 223
- PDF量: 523
- 被引次数: 0
出版历程
- 收稿日期: 2011-06-13
- 刊出日期: 2012-05-28

Finite element analysis on temperature field of bearing with shaft

1.
School of Mechatronics Engineering, Henan University of Science and Technology, Luoyang Henan 471003, China
2.
Shaanxi Automobile Group, Hande Axle Company Limited, Xi’an, 710201 China

摘要

摘要: 根据轴连轴承组件的结构及特点,建立了有限元模型,实现了对轴连轴承温度场的有限元分析.首先采用拟静力学方法分析出轴承工作时钢球的自转速度,然后计算出轴承在不同的内圈转速、轴向载荷和径向载荷下的功率损失,最后使用ANSYS软件计算出轴承的温度分布.通过算例分析了不同工况对轴连轴承工作温度分布的影响,并进行了试验验证,结果表明:轴向载荷和内圈转速对轴承温度分布影响较大,而径向载荷的变化对轴承温升影响不显著.
- 轴连轴承 /
- 有限元 /
- 温度场 /
- 功率损失 /
- 温度分布
Abstract: Finite element model based on the structure of bearing with shaft was set up.Its temperature field was analyzed by finite element method.First,angular speed of balls was analyzed through quasi-static method.Then power loss was gotten at various inner ring velocities,axial loads and radial loads.Finally,temperature distribution was calculated by ANSYS.Effects on temperature field were analyzed at different operating conditions by examples.The results validated by experiments show that axial load and inner ring velocity can affect temperature distribution strongly,but the effect of radial load is not significant.
- bearing with shaft /
- finite element /
- temperature field /
- power loss /
- temperature distribution

HTML

参考文献(17)

[1]	刘春浩,顾家铭,周赤忠,等.陀螺仪电动机转子轴承研究现状与展望[J].机械工程学报,2006,42(11):17-25. LIU Chunhao,GU Jiaming,ZHOU Chizhong,et al.Research of present state and prospective on gyro-spin bearings[J].Chinese Journal of Mechanical Engineering,2006,42(11):17-25.(in Chinese)
[2]	宁练,周孑民.滚动轴承内部温度状态监测技术[J].轴承,2007,(2):26-28. NING Lian,ZHOU Jiemin.Research on condition monitoring technique for internal temperature of rolling bearings[J].Bearing,2007,(2):26-28.(in Chinese)
[3]	葛泉江,闫国斌.某型航空发动机前中介轴承失效分析[J].航空发动机,2007,33(1):42-44. GE Quanjiang,YAN Guobin.Failure analysis of front intermediate bearing for an aero-engine[J].Aeroengine,2007,33(1):42-44.(in Chinese)
[4]	谢荣华,罗贵火.航空用高速滚动轴承失效分析[J].振动与冲击,2008,27(增刊),131-134. XIE Ronghua,LUO Guihuo.Failure analysis of high speed rolling bearing for aeroending[J].Journal of Vibration and Shock,2008,27(Supplement),131-134.(in Chinese)
[5]	Liu X L,Jiang M,Yang P.Non-newtonian thermal anlysis of point EHL contacts using the eyring model[J].Journal of Tribology,2005,127(1):70-81.
[6]	Nicolás J A M,De león Hijes F C G,Alhama F.Solution of temperature fields in hydrodynamics bearing by the numerical network method[J].Tribology International,2006,40(1):139-145.
[7]	Pouly F,Changenet C.Investigations on the power losses and thermal behaviour of rolling element bearings[J].Journal of Engineering Tribology,2010,224(9):925-933.
[8]	曹永.混合陶瓷角接触球轴承温度场分布的有限元分析.天冿:天冿大学,2008. CAO Yong.Finite-element analysis for temperature field of hybrid ceramic angular contact ball bearing.Tianjin:Tianjin University,2008.(in Chinese)
[9]	苏壮,李国权.航空发动机滑油系统断油时主推力球轴承的瞬态热分析[J].航空发动机,2009,35(2):24-27. SU Zhuang,LI Guoquan.Transient thermal analysis of main thrust ball bearing during fuel cut off for aeroengine oil system[J].Aeroengine,2009,35(2):24-27.(in Chinese)
[10]	Mizuta K J, Inoue T Y.Heat transfer characteristics between inner and outer rings of an angular ball bearing[J].Heat Transfer Asia Research,2003,32(1):42-57.
[11]	葛世东,梁波,郭向东,等.整体式轴连轴承组合结构:中国,200420075445.8.2006-12-20.
[12]	邓四二,贾群义,王燕霜.滚动轴承设计原理[M].北京:中国标准出版社,2009.
[13]	Kannel J W,Barber S A.Estimate of surface temperature during rolling contact[J].Tribology Transaction,1989,32(3):305-310.
[14]	沈军,马骏,刘伟强.一种接触热阻的数值计算方法[J].上海航天,2002(4):33-36. SHEN Jun,MA Jun,LIU Weiqiang.A numerical calculation method of thermal contact resistance[J].Aerospace Shanghai,2002(4):33-36.(in Chinese)
[15]	Harris T A.Rolling bearing analysis[M].5th ed.New York:John Wiley & Sons Inc.,2006.
[16]	焦育洁,吕新生,张锡昌.航空发动机主轴圆柱滚子轴承典型故障分析[J].轴承,2003(12):29-30. JIAO Yujie,LU Xingsheng,ZHANG Xichang.Analysis on typical failure of cylindrical roller bearing used in aero engine[J].Bearing,2003(12):29-30.(in Chinese)
[17]	Crecelius W J,Pirvics J.Computer program operation manual on “SHABERTH”-a computer program for the analysis of the Steady state and transient thermal performance of shaft-bearing systems.King of Prussia,PA:Engineering and Research Center of SKF Industries,A189240,1976.
