基于LMD的包络谱特征值在滚动轴承 故障诊断中的应用

杨宇; 王欢欢; 程军圣; 邹宪军

基于LMD的包络谱特征值在滚动轴承故障诊断中的应用

湖南大学汽车车身先进设计制造国家重点实验室, 长沙 410082

基金项目: 国家自然科学基金(51175158, 51075131); 湖南省自然科学基金(11JJ2026); 中央高校基本科研业务费专项基金; 湖南大学汽车车身先进设计制造国家重点实验室自主研究课题(60870002); 湖南省科技计划应用基础研究(2010FJ3165)

计量
- 文章访问数: 2128
- HTML浏览量: 285
- PDF量: 497
- 被引次数: 0
出版历程
- 收稿日期: 2011-06-24
- 刊出日期: 2012-05-28

Application of envelope spectrum characteristics based on LMD to roller bearing fault diagnosis

State key Laboratory of Advanced Design and Manufacture for Vehicle Body, Hunan University, Changsha 410082, China

摘要

摘要: 滚动轴承故障振动信号往往是多分量的调幅-调频信号,而传统包络分析方法需要根据经验设置滤波器的中心频率与带宽,因而会带来解调误差.基于此,提出了一种基于局域均值分解(local mean decomposition,简称LMD)的包络谱特征值的滚动轴承故障诊断方法.该方法可以将一个多分量的调幅-调频信号分解成若干瞬时频率具有物理意义的PF (product function,简称PF )分量之和,由于每一个PF分量是分量包络信号和纯调频信号的积,因此可以直接对包络信号进行频谱分析得到包络谱.然后定义信号在包络谱中不同故障特征频率处的幅值比为包络谱特征值,并以此作为特征向量输入到支持向量机分类器中,用以区分滚动轴承的工作状态和故障类型.对滚动轴承正常状态、内圈故障和外圈故障振动信号的分析结果表明了该方法的有效性.
- 局域均值分解 /
- 调制特征 /
- 滚动轴承 /
- 包络谱特征值 /
- 故障诊断
Abstract: Most roller bearing fault vibration signals are always multi-component amplitude-modulated and frequency-modulated (AM-FM) signals,however,the selection of central frequency of band-pass filter needs to be determined with experience in conventional envelope analysis method,which would bring demodulation error.To target this problem,a roller bearing fault diagnosis approach based on LMD (local mean decomposition) and envelope spectrum characteristics was proposed.Firstly,by using LMD method,the vibration signal of roller bearing can be decomposed into a set of product functions (PF) whose instantaneous frequencies owned physical sense and each of which was a product of an envelope signal and a purely frequency modulated signal.Secondly,spectrum analysis can be used directly to envelope signal and then the envelope spectrum can be obtained.Finally,the amplitudes ratios in different characteristic frequencies of envelope spectrum were defined as the envelope spectrum characteristics,which served as input parameters of support sector machine classifier to classify working condition and fault patterns of roller bearings.The analysis results demonstrate the effectiveness of the proposed method.
- local mean decomposition /
- modulation feature /
- roller bearing /
- envelope spectrum characteristics /
- fault diagnosis

HTML

参考文献(13)

[1]	Radcliff G A.Condition monitoring of rolling element bearings using the enveloping technique[M].London: Mechanical Engineering Publication Limited,1990:55-67.
[2]	Randall R B,Antoni J,chobsaard S.The relationship between spectral correlation and envelope analysis in the diagnostics of bearing faults and other cyclostationary machine signals[J].Mechanical Systems and Signal Processing,2001,15(5):945-962.
[3]	Olhede S,Walden A T.A generalized demodulation approach to time-frequency projections for multicomponent signals[J].Proceedings of the Royal Society A,2005,461(2059):2159-2179.
[4]	Rubini R,Meneghetti U.Application of the envelope and wavelet transform analyses for the diagnosis of incipient faults in ball bearings[J].Mechanical Systems and Signal Processing,2001,15(2):287-302.
[5]	Maragos P,Kaiser J F,Quatieri T F.On amplitude and frequency demodulation using energy operator[J].IEEE Transactions on Signal Processing,1993,41(4):1532- 1555.
[6]	Huang N E,Shen Z,Long S R.The empirical mode decomposition and the Hilbert spectrum for nonlinear and non-stationary time series analysis[J].Proceedings of the Royal Society of London Series,1998,454(1971):903-995.
[7]	Huang N E,Shen Z,Long S R.A new view of nonlinear water waves:the Hilbert spectrum[J].Annu Rev Fluid Mech,1999,31:417-457.
[8]	高强,杜小山,范虹,等.滚动轴承故障的EMD诊断方法研究[J].振动工程学报,2007,20(1):15-18. GAO Qiang,DU Xiaoshan,FAN Hong,et al.An empirical mode decomposition based method for rolling bearing fault diagnosis[J].Journal of Vibration Engineering,2007,20(1):15-18. (in Chinese)
[9]	YANG Yu,YU Dejie,CHENG Junsheng.A roller bearing fault diagnosis method based on EMD energy entropy and ANN[J].Journal of Sound and Vibration,2006,294(1-2):269-277.
[10]	DENG Yongjun,WANG wei.Boundary processing technique in EMD method and Hilbert transform[J].Chinese Science Bulletin,2001,46(11):257-263.
[11]	Smith J S.The local mean decomposition and its application to EEG perception data[J].Journal of the Royal Society Interface,2005,2(5):443-454.
[12]	程军圣,张亢,杨宇,等.局部均值分解与经验模式分解的对比研究.振动与冲击,2009,28(5):13-16. CHENG Junsheng,ZHANG Kang,YANG Yu,et al Comparison between the methods of local mean decomposition and empirical mode decomposition[J].Journal of Vibration and Shock,2009,28(5):13-16.(in Chinese)
[13]	许宝杰,张建民,徐小力,等.抑制EMD端点效应方法的研究[J].北京理工大学学报,2006,26(3):196-200. XU Baojie,ZHANG Jianmin,XU Xiaoli,et al.A study on the method of restraining the ending effect of empirical mode decomposition(EMD)[J].Transactions of Beijing Institute of Technology,2006,26(3):196-200.(in Chinese)
