采用碟形砂轮的面齿轮磨齿方法理论分析

彭先龙; 方宗德; 苏进展; 裴杉杉

采用碟形砂轮的面齿轮磨齿方法理论分析

1.
西北工业大学机电学院, 西安 710072
2.
中国兵器工业集团公司西北机电工程研究所, 陕西咸阳 712099

基金项目: 国家自然科学基金(50875211)

计量
- 文章访问数: 2014
- HTML浏览量: 117
- PDF量: 526
- 被引次数: 0
出版历程
- 收稿日期: 2011-06-23
- 刊出日期: 2012-05-28

Theory analysis for application grinding disk in face gear grinding

1.
School of Mechanical Engineering, Northwestern Polytechnical University, Xi’an 710072
2.
Northwest Institute of Mechanical & Electrical Engineering, China North Industries Group Corporation, Xianyang Shanxi 712099, China

摘要

摘要: 为了制造出高精度硬齿面面齿轮和获得抛物线传动误差并提高传动稳定性,提出一种采用碟形砂轮加工面齿轮的磨齿方法.分析了碟形砂轮磨削面齿轮的展成原理和碟形砂轮的运动,根据展成原理推导了碟形砂轮的齿面方程,使用渐开线失配的碟形砂轮和改变砂轮的运动,推导出双向修形面齿轮的齿面方程.建立了双向修形面齿轮和常规渐开线小齿轮啮合的齿面接触分析模型,齿面计算和齿面接触分析实例表明,采用碟形砂轮加工双向修形面齿轮的磨齿方法是可行的,获得了面齿轮抛物线传动误差,避免了边缘接触并提高了传动的稳定性.
- 面齿轮 /
- 碟形砂轮 /
- 磨削 /
- 展成 /
- 修形 /
- 齿面接触分析
Abstract: A method of tooth grinding for face gear machining by using grinding disk was proposed with the purpose to manufacture hardened face gear with high precision and obtain parabolic transmission errors and increase transmission stability.The generation theory and grinding disk motion of face gear abraded by grinding disk were analyzed,the surface equation of grinding disk was deduced according to the generation theory,and the double crowned tooth surface equation of face gear was derived based on using grinding disk with mismatch involute and modified movement of grinding disk.The model of tooth contact analysis of double crowned face gear meshing with traditional involute pinion was established.Instances of tooth surface calculation and tooth contact analysis indicate that the method of gear grinding applied to manufacture double crowned face gear through grinding disk is feasible,parabolic transmission errors of face gear can be obtained,edge contact is avoided and is enhanced the stability of transmission.
- face gear /
- grinding disk /
- grinding /
- generation /
- modification /
- tooth contact analysis

HTML

参考文献(13)

[1]	Litvin F L.Gear geometry and applied theory[M].New Jersey:PTR Prentice Hall,1994.
[2]	Bill R C.Summary highlights of the advanced rotorcraft transmission (ART) program.AIAA-1992-3362,1992.
[3]	Litvin F L,Fuentes A,Howkins M.Design,generation and TCA of new type of asymmetric face gear drive with modified geometry[J].Computer Methods in Applied Mechanics Engineering,2001,190(43-44):5837-5865.
[4]	Litvin F L,Fuentes A.Gear geometry and applied theory[M].New York:Cambridge University Press,2004.
[5]	沈云波.面齿轮传动齿面设计理论及插齿技术研究.西安:西北工业大学,2009. SHEN Yunbo.The design theory of tooth surface and technology of gear shaping of face-gear drive.Xi’an:Northwestern Polytechnical University,2009.(in Chinese)
[6]	Litvin F L,Perez I G,Fuentes A,et al.Design,generation,and stress analysis of face-gear drive with helical pinion[J].Computer Methods in Applied Mechanics and Engineering,2005,194(36-38):3870-3901.
[7]	赵宁,曾晓春,郭辉,等.斜齿面齿轮齿面仿真及其轮齿接触分析[J].航空动力学报,2008,23(10):1927-1932. ZHAO Ning,ZENG Xiaochun,GUO Hui,et al.Tooth contact analysis of face gear drive with helical pinion and simulation of the tooth face[J].Journal of Aerospace Power,2008,23(10):1927-1932.(in Chinese)
[8]	郭辉.面齿轮滚齿加工方法及其啮合性能研究.西安:西北工业大学,2009. GUO Hui.Research on hobbing face-gear and gearing performance.Xi’an:Northwestern Polytechnical University,2009.(in Chinese)
[9]	Stadtfeld H J.Coniface face gear cutting and grinding..http://www.gearsolutions.com/article/detail/6020/coniface-face-gear-cutting-and-grinding.
[10]	赵宁,曾晓春,郭辉,等.直齿面齿轮修形及承载接触分析[J].航空动力学报,2008,23(11):2142-2146. ZHAO Ning,ZENG Xiaochun,GUO Hui,et al.Modification and loaded contact analysis of spur fa ce gear[J].Journal of Aerospace Power,2008,23(11):2142-2146.(in Chinese)
[11]	Zanzi C,Pedrero J I.Application of modified geometry of face gear drive[J].Computer Methods in Applied Mechanics and Engineering,2005,194(36-38):3047-3066.
[12]	Litvin F L,Fuentes A,Zanzi C,et al.Design,generation,and stress analysis of two versions of geometry of face-gear drives[J].Mechanism and Machine Theory,2002,37(10):1179-1211.
[13]	Litvin F L,Fuentes A,Perez I G,et al.Modified involute helical gears:computerized design,simulation of meshing and stress analysis[J].Computer Methods in Applied Mechanics and Engineering,2003,192(33-34):3619-3655.
