基于变形协调的行星轮系均载特性研究

杜进辅; 方宗德; 王宝宾; 董皓

基于变形协调的行星轮系均载特性研究

西北工业大学机电学院, 西安 710072

基金项目: 国家自然科学基金(50875211)

计量
- 文章访问数: 1881
- HTML浏览量: 139
- PDF量: 550
- 被引次数: 0
出版历程
- 收稿日期: 2011-06-08
- 刊出日期: 2012-05-28

Study on load sharing behavior of planetary gear train based on deformation compatibility

School of Mechanical Engineering, Northwestern Polytechnical University, Xi’an 710072, China

摘要

摘要: 以2K-H行星齿轮传动系统为研究对象,根据整个系统构成功率流动闭环的特点,建立了系统的力矩平衡条件和变形协调条件,并运用当量啮合误差理论,计算了各个行星轮以及系统的均载系数.从静力学角度分析了各构件的制造误差、安装误差以及浮动对行星传动均载性能的影响.提出了一种新的算法,以供工程应用参考.
- 行星齿轮 /
- 变形协调 /
- 均载 /
- 误差 /
- 浮动
Abstract: The deformation compatibility equations and the torque balance equations were found of the 2K-H-type planetary transmission system based on the characteristic that the system composed a closed-loop of power flow.In consideration of the manufacturing error,assembly error and float of the parts,the load sharing coefficient of each planetary gear was calculated by using the theory of equivalent mesh error and equivalent mesh stiffness.The effects of the errors on load sharing were studied.The study provides useful theoretical guideline for the design of planetary gear systems.
- planetary gear train /
- deformation compatibility /
- load sharing /
- errors /
- float

HTML

参考文献(12)

[1]	Kahramn A.Load sharing characteristics of planetary trans-missions[J].Mecharism and Machine Theory,1994,29(8):1151-1165.
[2]	Kahramn A.Static load sharing characteristics of transmission planetary gear sets:model and experiment[J].Society of Automotive Engineers,1999,(1):1954-1963.
[3]	Krantz T L.A method to analyze and optimize the load sharing of split path transmissions.NASA Technical Memorandum 107201,1996.
[4]	日高照晃,山本信行,石田武.行星齿轮装置均载机构中的各种误差和载荷分配的关系 //日本机械学会论文集.东京:日本机械学会,1986,52(480):2200-2206. Hidaka T,Sugimoto N,Ishida T.Effects of errors of elements on load distribution in planetary gears with various load equalizing machanisms //Japanese Mechanical Academic Society Collection. Tokyo:The Japan Society of Mechanical Engineers,1986,52(480):2200-2206.(in Japanese)
[5]	袁茹,王三民,沈允文.行星齿轮传动的功率分流动态均衡优化设计[J].航空动力学报,2000,15(4):410-412. YUAN Ru,WANG Sanmin,SHEN Yunwen.Dynamic opt-imum design of power shared out equally among the planetary gears[J].Journal of Aerospace Power,2000,15(4):410-412.(in Chinese)
[6]	肖铁英,袁盛治,陆卫杰.行星齿轮机构均载系数的计算方法[J].东北重型机械学院学报,1992,16(4):290-295. XIAO Tieying,YUAN Shengzhi,LU Weijie.Calcula-tive method of 1oad balence coefficint in pla-netary gear[J].Journal of Northeast Heavy Machinery Institute,1992,16(4):290-295.(in Chinese)
[7]	陆俊华,李斌,朱如鹏.行星齿轮传动静力学均载分析[J].机械科学与技术,2005,24(10):702-704,709. LU Junhua,LI Bin,ZHU Rupeng.Analysis of static load sharing in planetary gearing[J].Mechanical Science and Technology for Aerospace Engineering,2005,24(10):702-704,709.(in Chinese)
[8]	周惠琴,李素有,吴立言.行星齿轮传动系统均载分析[J].机械科学与技术,2008,27(9):1239-1242. ZHOU Huiqin,LI Suyou,WU Liyan.Analysis of static load sharing in a planetary gearing[J].Mechanical Science and Technology for Aerospace Engineering,2008,27(9):1239-1242.(in Chinese)
[9]	邵晓荣.齿轮制造及安装误差对行星齿轮均载系数的影响[J].东北重型机械学院学报,1994,18(4):306-309. SHAO Xiaorong.Influence of load sharing coefficient on the manufacture and assemble error of the planetry gear NGW[J].Journal of Northeast Heavy Machinery Institute.1994,18(4):306-309.(in Chinese)
[10]	李阳,刘光磊,刘更,等.基于间隙浮动的行星齿轮传动系统静力学均载分析[J].机械科学与技术,2009,28(8):1115-1120. LI Yang,LIU Guanglei,LIU Geng,et al.Analysis of static load sharing in a planetary gear set with gap for gear floating[J].Mechanical Science and Technology for Aerospace Engineering,2009,28(8):1115-1120.(in Chinese)
[11]	王宇航,佟占胜,吴秀英,等.行星齿轮传动的均载机构及选择[J].重型机械,2010(增刊2):158-162. WANG Yuhang,TONG Zhansheng,WU Xiuying,et al.Load balancing mechanism of planetary gear transmission and its selection[J].Heavy Machinery,2010(Supplement 2):158-162.(in Chinese)
[12]	方宗德,沈允文,黄镇东.2K-H行星减速器的动态特性[J].西北工业大学学报,1990,10(4):361-371. FANG Zongde,SHEN Yunwen,HUANG Zhendong.Dynamic characteristics of 2K-H planetary gearing[J].Journal of Northwestern Polytechnical University,1990,10(4):361-371.(in Chinese)
