炭化层疏松/致密结构的三元乙丙烧蚀模型

杨飒; 何国强; 李江; 李强; 孙翔宇; 胡淑芳

炭化层疏松/致密结构的三元乙丙烧蚀模型

1.
西北工业大学动力与能源学院燃烧、流动和热结构国家级重点实验室, 西安 710072
2.
中国航天科工集团第六研究院, 呼和浩特 010000

基金项目: 国家自然科学基金(E060405); 国家重点基础研究发展计划(61371)

计量
- 文章访问数: 1855
- HTML浏览量: 140
- PDF量: 678
- 被引次数: 0
出版历程
- 收稿日期: 2011-06-07
- 刊出日期: 2012-05-28

EPDM ablation model considering of porous/compact structure of charring layer

1.
National Key Laboratory of Combustion, Flow and Thermo-Structure, School of Power and Energy, Northwestern Polytechnical University, Xi’an 710072
2.
The Sixth Academy of China Aerospace Science and Industry Corporation, Hohhot 010000, China

摘要

摘要: 分析了烧蚀发动机和高过载烧蚀发动机实验得到EPDM(三元乙丙)的炭化层结构,获得烧蚀过程炭化层结构形成变化的机理,建立了考虑疏松致密结构的多孔炭化层物理模型.模型中炭化层为非均质的多孔可渗透介质,孔隙内部存在气体扩散和热化学反应;炭化层中热解气体沉积效应形成致密结构.在多孔介质流动与传热算法基础上建立了模拟绝热材料烧蚀过程的数值方法,计算得到的炭化率、质量烧蚀率和炭化层的多孔结构与实验结果相吻合,证明了本烧蚀模型能够准确地描述绝热材料的热化学烧蚀过程,并为耦合烧蚀模型的建立提供数值算法基础.
- 三元乙丙 /
- 疏松/致密炭化层 /
- 体烧蚀 /
- 烧蚀模型 /
- 固体火箭发动机
Abstract: By analyzing the characteristics of charring layers obtained in ablation motor and simulating erosion motor,the forming and consumption mechanisms of charring layer were analyzed,and ablation model considering the porosity of charring layer was developed.With the model,the charring layer was described as gas-saturated porous media with dense layer and porous layer,thermo-chemical reaction and gas diffusion existed in the pores of charring layer,and the compact structure of charring layer was formed by sediment of decomposition gas.Based on numerical investigation on flow and convection in porous media,a numerical model was presented to simulate the ablation process,and the calculated ablative rates,mass loss rates and the structures of charring layer agree with experimental results.The ablation model has been proved to simulate the process of the thermo-chemical ablation reasonably,and to provide the numerical method for all ablation models considering the thermo-chemical ablation and mechanical erosion.
- EPDM(ethylene-propylene-diene mononer) /
- porous/compact charring layer /
- volumetric ablation /
- ablation model /
- solid rocket motor

HTML

参考文献(12)

[1]	何国强.包覆层烧蚀性能计算及实验分析.西安:西北工业大学,1988. HE Guoqiang.Calculation and analysis of ablation experiment of a liner inhibitor.Xi’an:Northwestern Polytechnical University,1988.(in Chinese)
[2]	Yang B C.A theoretical study of thermo-mechanical erosion of high-temperature ablatives.PA,USA:University of Pennsylvania,1992.
[3]	Yang B C,Cheung F B,Koo J H.Modeling of one-dimensional thermomechanical erosion of high temperature ablatives[J].Journal of Applied Mechanics, 1993,60(4):1027- 1032.
[4]	何洪庆,严红.EPDM的烧蚀模型[J].推进技术,1999,20(4):36-39. HE Hongqing,YANG Hong.Ablation model of EPDM[J].Journal of Propulsion Technology,1999,20(4):36-39.(in Chinese)
[5]	易法军,孟松鹤,梁军,等.防热复合材料高温体积烧蚀模型[J].哈尔滨工业大学学报,2001,33(6):725-728. YI Fajun,MENG Songhe,LIANG Jun,et al.A high-temperature volumetric ablation model for thermal protective composites[J].Journal of Harbin Institute of Technology,2001,33(6):725-728.(in Chinese)
[6]	余晓京,何国强,李江,等.富氧环境下绝热层烧蚀模型[J].固体火箭技术,2006,29(2):113-116. YU Xiaojing,HE Guoqiang,LI Jiang,et al.Ablation model of insulation in oxygen-rich environment[J].Journal of Solid Rocket Technology,2006,29(2):113-116.(in Chinese)
[7]	刘泽祥.绝热材料炭化层制备技术及剥落机理试验研究.西安:西北工业大学,2009. LIU Zexiang.Production technology of char layer of insulator and experimental investigation of erosion mechanism.Xi’an:Northwestern Polytechnical University,2009.(in Chinese)
[8]	刘洋,丽江,何国强,等.颗粒冲刷条件下三元乙丙绝热材料烧蚀特性实验[J].推进技术,2010,31(5):612-617. LIU Yang,LI Jiang,HE Guoqiang,et al.Experiment on ablation characteristic of EPDM insulator under particles erosion condition[J].Journal of Propulsion Technology,2010,31(5):612-617.(in Chinese)
[9]	林瑞泰. 多孔介质传热传质引论[M].北京:科学出版社, 1995.
[10]	杨飒.基于炭层孔隙结构的热化学烧蚀模型研究.西安:西北工业大学,2009. YANG Sa.Thermo-chemical ablation model of ablative materials considering structure of charred layer.Xi’an:Northwestern Polytechnical University,2009.(in Chinese)
[11]	尹洪峰,徐永东,张立同.热解条件对热解碳沉积模式和形貌的影响[J].无机材料学报,1999,14(5):69-74. YIN Hongfeng,XU Yongdong,ZHANG Litong.Effect of deposition on deposition mode and morphology of pyrolytic carbon[J].Journal of Inorganic Materials,1999,14(5):69-74.(in Chinese)
[12]	徐善玮,侯晓,张宏安.固体火箭发动机内绝热层烧蚀质量损失计算[J].固体火箭技术,2003,26(3):28-31. XU Shanwei,HOU Xiao,ZHANG Hongan.Calculation of internal insulation ablation mass loss of solid rocket motor[J].Journal of Solid Rocket Technology,2003,26(3):28-31.(in Chinese)
